Create a schema using the Schema Registry API

Last update: April 2, 2025

CREATED FOR:

  • Developer

The Schema Registry is used to access the Schema Library within Adobe Experience Platform. The Schema Library contains resources made available to you by Adobe, Experience Platform partners, and vendors whose applications you use. The registry provides a user interface and RESTful API from which all available library resources are accessible.

This tutorial uses the Schema Registry API to walk you through the steps to compose a schema using a standard class. If you would prefer to use the user interface in Experience Platform, the Schema Editor Tutorial provides step-by-step instructions for performing similar actions in the schema editor.

NOTE
If you are ingesting CSV data into Experience Platform, you can map that data to an XDM schema created by AI-generated recommendations (currently in beta) without having to manually create the schema yourself.

Getting started

This guide requires a working understanding of the following components of Adobe Experience Platform:

  • Experience Data Model (XDM) System: The standardized framework by which Experience Platform organizes customer experience data.
    • Basics of schema composition: Learn about the basic building blocks of XDM schemas, including key principles and best practices in schema composition.
  • Real-Time Customer Profile: Provides a unified, real-time consumer profile based on aggregated data from multiple sources.
  • Sandboxes: Experience Platform provides virtual sandboxes which partition a single Experience Platform instance into separate virtual environments to help develop and evolve digital experience applications.

Before starting this tutorial, please review the developer guide for important information that you need to know in order to successfully make calls to the Schema Registry API. This includes your {TENANT_ID}, the concept of “containers”, and the required headers for making requests (with special attention to the Accept header and its possible values).

This tutorial walks through the steps of composing a Loyalty Members schema that describes data related to the members of a retail loyalty program. Before beginning, you may wish to preview the complete Loyalty Members schema in the appendix.

Compose a schema with a standard class

A schema can be thought of as the blueprint for the data you wish to ingest into Experience Platform. Each schema is composed of a class and zero or more schema field groups. In other words, you do not have to add a field group in order to define a schema, but in most cases at least one field group is used.

Assign a class

The schema composition process begins with the selection of a class. The class defines key behavioral aspects of the data (record vs time series), as well as the minimum fields that are required to describe the data that will be ingested.

The schema you are making in this tutorial uses the XDM Individual Profile class. XDM Individual Profile is an standard class provided by Adobe for defining record behavior. More information on behavior can be found in basics of schema composition.

To assign a class, an API call is made to create (POST) a new schema in the tenant container. This call includes the class the schema will implement. Each schema may only implement one class.

API format

POST /tenant/schemas

Request

The request must include an allOf attribute which references the $id of a class. This attribute defines the “base class” that the schema will implement. In this example, the base class is the XDM Individual Profile class. The $id of the XDM Individual Profile class is used as the value of the $ref field in the allOf array below.

curl -X POST \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -H 'Content-Type: application/json' \
  -d '{
        "type": "object",
        "title": "Loyalty Members",
        "description": "Information for all members of the loyalty program",
        "allOf": [
            {
              "$ref": "https://ns.adobe.com/xdm/context/profile"
            }
        ]
      }'

Response

A successful request returns HTTP Response Status 201 (Created) with a response body that contains the details of the newly created schema, including the $id, meta:altIt, and version. These values are read-only and are assigned by the Schema Registry.

{
  "$id": "https://ns.adobe.com/tenantId/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:altId": "_tenantId.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:resourceType": "schemas",
  "version": "1.0",
  "title": "Loyalty Members",
  "type": "object",
  "description": "Information for all members of the loyalty program",
  "allOf": [
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": false,
  "meta:abstract": false,
  "meta:extends": [
    "https://ns.adobe.com/xdm/common/auditable",
    "https://ns.adobe.com/xdm/data/record",
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673310304048,
    "repo:lastModifiedDate": 1673310304048,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "6d2ed8acd9c3b768a44de29e069fc6f71329d2550f708381d22fa8bf8c192366",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:class": "https://ns.adobe.com/xdm/context/profile",
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_tenantId"
}
