Criar um esquema usando a API Schema Registry

Last update: Tue Jul 16 2024 00:00:00 GMT+0000 (Coordinated Universal Time)

Tópicos:

Criado para:

Desenvolvedor

O Schema Registry é usado para acessar o Schema Library no Adobe Experience Platform. O Schema Library contém recursos disponibilizados a você pelo Adobe, parceiros Experience Platform e fornecedores cujos aplicativos você usa. O registro fornece uma interface de usuário e a API RESTful a partir da qual todos os recursos de biblioteca disponíveis podem ser acessados.

Este tutorial usa a API Schema Registry para orientá-lo pelas etapas de composição de um esquema usando uma classe padrão. Se você preferir usar a interface de usuário no Experience Platform, o Tutorial do Editor de Esquemas fornece instruções passo a passo para executar ações semelhantes no editor de esquemas.

NOTE

Se você estiver assimilando dados CSV na Platform, poderá mapear esses dados para um esquema XDM criado por recomendações geradas por IA (atualmente na versão beta) sem precisar criar manualmente o esquema.

Introdução

Este manual necessita de uma compreensão funcional dos seguintes componentes da Adobe Experience Platform:

Experience Data Model (XDM) System: a estrutura padronizada pela qual o Experience Platform organiza os dados de experiência do cliente.
- Noções básicas sobre a composição de esquema: saiba mais sobre os blocos de construção básicos de esquemas XDM, incluindo princípios-chave e práticas recomendadas na composição de esquema.
Real-Time Customer Profile: Fornece um perfil de consumidor unificado em tempo real com base em dados agregados de várias fontes.
Sandboxes: Experience Platform fornece sandboxes virtuais que particionam uma única instância do Platform em ambientes virtuais separados para ajudar a desenvolver aplicativos de experiência digital.

Antes de iniciar este tutorial, consulte o guia do desenvolvedor para obter informações importantes que você precisa saber para fazer chamadas para a API Schema Registry com êxito. Isso inclui o {TENANT_ID}, o conceito de "contêineres" e os cabeçalhos necessários para fazer solicitações (com atenção especial ao cabeçalho Accept e seus valores possíveis).

Este tutorial aborda as etapas de composição de um esquema de Membros de fidelidade que descreve dados relacionados aos membros de um programa de fidelidade de varejo. Antes de começar, talvez você queira visualizar o esquema completo de Membros de Fidelidade no apêndice.

Compor um esquema com uma classe padrão

Um esquema pode ser considerado como o blueprint dos dados que você deseja assimilar em Experience Platform. Cada esquema é composto por uma classe e zero ou mais grupos de campos de esquema. Em outras palavras, não é necessário adicionar um grupo de campos para definir um esquema, mas, na maioria dos casos, pelo menos um grupo de campos é usado.

Atribuir uma classe

O processo de composição de esquema começa com a seleção de uma classe. A classe define os principais aspectos comportamentais dos dados (registro versus série temporal), bem como os campos mínimos necessários para descrever os dados que serão assimilados.

O esquema que você está fazendo neste tutorial usa a classe XDM Individual Profile. XDM Individual Profile é uma classe padrão fornecida pelo Adobe para definir o comportamento do registro. Mais informações sobre comportamento podem ser encontradas em noções básicas da composição de esquema.

Para atribuir uma classe, é feita uma chamada à API para criar (POST) um novo esquema no container do locatário. Essa chamada inclui a classe que o esquema implementará. Cada esquema só pode implementar uma classe.

Formato da API

POST /tenant/schemas

Solicitação

A solicitação deve incluir um atributo allOf que faça referência a $id de uma classe. Esse atributo define a "classe base" que o esquema implementará. Neste exemplo, a classe base é a classe XDM Individual Profile. O $id da classe XDM Individual Profile é usado como o valor do campo $ref na matriz allOf abaixo.

curl -X POST \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -H 'Content-Type: application/json' \
  -d '{
        "type": "object",
        "title": "Loyalty Members",
        "description": "Information for all members of the loyalty program",
        "allOf": [
            {
              "$ref": "https://ns.adobe.com/xdm/context/profile"
            }
        ]
      }'

Resposta

Uma solicitação bem-sucedida retorna o Status de Resposta HTTP 201 (Criado) com um corpo de resposta que contém os detalhes do esquema recém-criado, incluindo $id, meta:altIt e version. Esses valores são somente leitura e são atribuídos por Schema Registry.

{
  "$id": "https://ns.adobe.com/tenantId/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:altId": "_tenantId.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:resourceType": "schemas",
  "version": "1.0",
  "title": "Loyalty Members",
  "type": "object",
  "description": "Information for all members of the loyalty program",
  "allOf": [
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": false,
  "meta:abstract": false,
  "meta:extends": [
    "https://ns.adobe.com/xdm/common/auditable",
    "https://ns.adobe.com/xdm/data/record",
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673310304048,
    "repo:lastModifiedDate": 1673310304048,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "6d2ed8acd9c3b768a44de29e069fc6f71329d2550f708381d22fa8bf8c192366",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:class": "https://ns.adobe.com/xdm/context/profile",
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_tenantId"
}

Pesquisar um esquema

Para exibir o esquema recém-criado, execute uma solicitação de pesquisa (GET) usando o URI meta:altId ou o URI $id codificado por URL para o esquema.

Formato da API

GET /tenant/schemas/{SCHEMA_ID}

Parâmetro

Descrição

{SCHEMA_ID}

O meta:altId ou o $id codificado na URL do esquema que você deseja pesquisar.

Solicitação

curl -X GET \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas/https%3A%2F%2Fns.adobe.com%2F{TENANT_ID}%2Fschemas%2F533ca5da28087c44344810891b0f03d9\
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -H 'Accept: application/vnd.adobe.xed+json; version=1'

Resposta

O formato da resposta depende do cabeçalho Accept enviado com a solicitação. Tente experimentar com diferentes cabeçalhos Accept para ver qual deles atende melhor às suas necessidades.

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:resourceType": "schemas",
  "version": "1.0",
  "title": "Loyalty Members",
  "type": "object",
  "description": "Information for all members of the loyalty program",
  "allOf": [
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": false,
  "meta:abstract": false,
  "meta:extends": [
    "https://ns.adobe.com/xdm/common/auditable",
    "https://ns.adobe.com/xdm/data/record",
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673310304048,
    "repo:lastModifiedDate": 1673310304048,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "6d2ed8acd9c3b768a44de29e069fc6f71329d2550f708381d22fa8bf8c192366",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:class": "https://ns.adobe.com/xdm/context/profile",
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}",
  "meta:allFieldAccess": true
}

Adicionar um grupo de campos add-a-field-group

Agora que o esquema Membros de Fidelidade foi criado e confirmado, é possível adicionar grupos de campos a ele.

Há diferentes grupos de campos padrão disponíveis para uso, dependendo da classe do esquema selecionado. Cada grupo de campos contém um campo intendedToExtend que define as classes com as quais esse grupo de campos é compatível.

Os grupos de campos definem conceitos, como "nome" ou "endereço", que podem ser reutilizados em qualquer esquema que precise capturar essas mesmas informações.

Formato da API

PATCH /tenant/schemas/{SCHEMA_ID}

Parâmetro

Descrição

{SCHEMA_ID}

O meta:altId ou o $id codificado na URL do esquema ao qual você está adicionando o grupo de campos.

Solicitação

Esta solicitação atualiza o esquema Membros de Fidelidade para incluir os campos no grupo de campos Detalhes Demográficos (profile-person-details).

Ao adicionar o grupo de campos profile-person-details, o esquema Membros de Fidelidade agora captura informações demográficas para membros do programa de fidelidade, como nome, sobrenome e aniversário.

curl -X PATCH \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas/_{TENANT_ID}.schemas.533ca5da28087c44344810891b0f03d9 \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'Content-Type: application/json' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -d '[
        { "op": "add", "path": "/allOf/-", "value":  {"$ref": "https://ns.adobe.com/xdm/context/profile-person-details"}}
      ]'

Resposta

A resposta mostra o grupo de campos recém-adicionado na matriz meta:extends e contém um $ref para o grupo de campos no atributo allOf.

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:resourceType": "schemas",
  "version": "1.1",
  "title": "Loyalty Members",
  "type": "object",
  "description": "Information for all members of the loyalty program",
  "allOf": [
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile-person-details",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [
    "https://ns.adobe.com/xdm/context/profile-person-details",
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": false,
  "meta:abstract": false,
  "meta:extends": [
    "https://ns.adobe.com/xdm/context/profile-person-details",
    "https://ns.adobe.com/xdm/common/auditable",
    "https://ns.adobe.com/xdm/data/record",
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673310304048,
    "repo:lastModifiedDate": 1673310912096,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "b480f28a35f356b237fc129e796074a3f33a7a67df273f6a8beaee1ec6465540",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:class": "https://ns.adobe.com/xdm/context/profile",
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}",
  "meta:descriptorStatus": {
    "result": []
  }
}

Adicionar mais grupos de campos

Os esquemas de Membros de Fidelidade exigem mais dois grupos de campos padrão, que podem ser adicionados repetindo as etapas com outro grupo de campos.

TIP

Vale a pena revisar todos os grupos de campo disponíveis para se familiarizar com os campos incluídos em cada um. Você pode listar (GET) todos os grupos de campos disponíveis para uso com uma classe específica executando uma solicitação em cada contêiner "global" e "locatário", retornando apenas os grupos de campos em que o campo "meta:intendedToExtend" corresponde à classe que você está usando. Nesse caso, é a classe XDM Individual Profile, então o XDM Individual Profile $id é usado:

code language-http
`GET /global/fieldgroups?property=meta:intendedToExtend==https://ns.adobe.com/xdm/context/profile GET /tenant/fieldgroups?property=meta:intendedToExtend==https://ns.adobe.com/xdm/context/profile`

Formato da API

PATCH /tenant/schemas/{SCHEMA_ID}

Parâmetro

Descrição

{SCHEMA_ID}

O meta:altId ou o $id codificado na URL do esquema que você está atualizando.

Solicitação

Essa solicitação atualiza o esquema Membros de Fidelidade para incluir os campos nos seguintes grupos de campos padrão:

Detalhes de Contato Pessoal (profile-personal-details): adiciona informações de contato, como endereço residencial, endereço de email e telefone residencial.
Detalhes de Fidelidade (profile-loyalty-details): adiciona informações de contato, como endereço residencial, endereço de email e telefone residencial.

curl -X PATCH \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas/_{TENANT_ID}.schemas.533ca5da28087c44344810891b0f03d9 \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'Content-Type: application/json' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -d '[
        { "op": "add", "path": "/allOf/-", "value":  {"$ref": "https://ns.adobe.com/xdm/context/profile-personal-details"}},
        { "op": "add", "path": "/allOf/-", "value":  {"$ref": "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details"}}
      ]'

Resposta

A resposta mostra os grupos de campos recém-adicionados na matriz meta:extends e contém um $ref para o grupo de campos no atributo allOf.

O esquema Membros de Fidelidade agora deve conter quatro valores $ref na matriz allOf: profile, profile-person-details, profile-personal-details e profile-loyalty-details conforme mostrado abaixo.

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:resourceType": "schemas",
  "version": "1.2",
  "title": "Loyalty Members",
  "type": "object",
  "description": "Information for all members of the loyalty program",
  "allOf": [
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile-person-details",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile-personal-details",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [
    "https://ns.adobe.com/xdm/context/profile-person-details",
    "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
    "https://ns.adobe.com/xdm/context/profile-personal-details",
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": false,
  "meta:abstract": false,
  "meta:extends": [
    "https://ns.adobe.com/xdm/context/profile-person-details",
    "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
    "https://ns.adobe.com/xdm/context/profile-personal-details",
    "https://ns.adobe.com/xdm/common/auditable",
    "https://ns.adobe.com/xdm/data/record",
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673310304048,
    "repo:lastModifiedDate": 1673311559934,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "1de5ed1a07e3478719952f0a8c94d5e5390d5a9a998761adb4cf1989137fd6ea",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:class": "https://ns.adobe.com/xdm/context/profile",
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}",
  "meta:descriptorStatus": {
    "result": []
  }
}

Definir um novo grupo de campos

Embora o grupo de campos padrão Detalhes de fidelidade forneça campos úteis relacionados à fidelidade para o esquema, há campos de fidelidade adicionais que não estão incluídos em nenhum grupo de campos padrão.

Para adicionar esses campos, você pode definir seus próprios grupos de campos personalizados dentro do container tenant. Esses grupos de campos são exclusivos de sua organização e não podem ser visualizados ou editados por ninguém fora dela.

Para criar (POST) um novo grupo de campos, sua solicitação deve incluir um campo meta:intendedToExtend contendo $id para a(s) classe(s) base com a(s) qual(is) o grupo de campos é compatível, juntamente com as propriedades que o grupo de campos incluirá.

Quaisquer propriedades personalizadas devem ser aninhadas em seu TENANT_ID para evitar colisões com outros grupos de campos ou campos.

Formato da API

POST /tenant/fieldgroups

Solicitação

Esta solicitação cria um novo grupo de campos que tem um objeto loyaltyTier contendo quatro campos específicos para um programa de fidelidade específico de uma empresa: id, effectiveDate, currentThreshold e nextThreshold.

curl -X POST\
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/fieldgroups\
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -H 'content-type: application/json' \
  -d '{
        "type": "object",
        "title": "Loyalty Tier",
        "meta:intendedToExtend": [
          "https://ns.adobe.com/xdm/context/profile"
        ],
        "description": "Captures info about the current loyalty tier of a customer.",
        "definitions": {
          "loyaltyTier": {
            "properties": {
              "_{TENANT_ID}": {
                "type": "object",
                "properties": {
                  "loyaltyTier": {
                    "type": "object",
                    "properties": {
                      "id": {
                        "title": "Loyalty Tier Identifier",
                        "type": "string",
                        "description": "Loyalty Tier Identifier."
                      },
                      "effectiveDate": {
                        "title": "Effective Date",
                        "type": "string",
                        "format": "date-time",
                        "description": "Date the member joined their current loyalty tier."
                      },
                      "currentThreshold": {
                        "title": "Current Point Threshold",
                        "type": "integer",
                        "description": "The minimum number of loyalty points the member must maintain to remain in the current tier."
                      },
                      "nextThreshold": {
                        "title": "Next Point Threshold",
                        "type": "integer",
                        "description": "The number of loyalty points the member must accrue to graduate to the next tier."
                      }
                    }
                  }
                }
              }
            }
          }
        },
        "allOf": [
          {
            "$ref": "#/definitions/loyaltyTier"
          }
        ]
      }'

Resposta

Uma solicitação bem-sucedida retorna o Status de Resposta HTTP 201 (Criado) com um corpo de resposta contendo os detalhes do grupo de campos recém-criado, incluindo $id, meta:altIt e version. Esses valores são somente leitura e são atribuídos por Schema Registry.

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
  "meta:altId": "_{TENANT_ID}.mixins.9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
  "meta:resourceType": "mixins",
  "version": "1.0",
  "title": "Loyalty Tier",
  "type": "object",
  "description": "Captures info about the current loyalty tier of a customer.",
  "definitions": {
    "loyaltyTier": {
      "properties": {
        "_{TENANT_ID}": {
          "type": "object",
          "properties": {
            "loyaltyTier": {
              "type": "object",
              "properties": {
                "id": {
                  "title": "Loyalty Tier Identifier",
                  "type": "string",
                  "description": "Loyalty Tier Identifier.",
                  "meta:xdmType": "string"
                },
                "effectiveDate": {
                  "title": "Effective Date",
                  "type": "string",
                  "format": "date-time",
                  "description": "Date the member joined their current loyalty tier.",
                  "meta:xdmType": "date-time"
                },
                "currentThreshold": {
                  "title": "Current Point Threshold",
                  "type": "integer",
                  "description": "The minimum number of loyalty points the member must maintain to remain in the current tier.",
                  "meta:xdmType": "int"
                },
                "nextThreshold": {
                  "title": "Next Point Threshold",
                  "type": "integer",
                  "description": "The number of loyalty points the member must accrue to graduate to the next tier.",
                  "meta:xdmType": "int"
                }
              },
              "meta:xdmType": "object"
            }
          },
          "meta:xdmType": "object"
        }
      }
    }
  },
  "allOf": [
    {
      "$ref": "#/definitions/loyaltyTier",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": true,
  "meta:abstract": true,
  "meta:intendedToExtend": [
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673313004645,
    "repo:lastModifiedDate": 1673313004645,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "98e5d48808f5a4d9655493777389568a2581cfce013351ab9e1595d82f698dd6",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}"
}

Adicionar o grupo de campos personalizados ao esquema

Agora você pode seguir as mesmas etapas para adicionar um grupo de campos padrão para adicionar este grupo de campos recém-criado ao esquema.

Formato da API

PATCH /tenant/schemas/{SCHEMA_ID}

Parâmetro

Descrição

{SCHEMA_ID}

O meta:altId ou o $id codificado na URL do esquema.

Solicitação

Essa solicitação atualiza (PATCH) o esquema Membros de fidelidade para incluir os campos no novo grupo de campos "Camada de fidelidade".

curl -X PATCH \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas/_{TENANT_ID}.schemas.533ca5da28087c44344810891b0f03d9 \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'Content-Type: application/json' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -d '[
        { "op": "add", "path": "/allOf/-", "value":  {"$ref": "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691"}}
      ]'

Resposta

Você pode ver que o grupo de campos foi adicionado com êxito porque a resposta agora mostra o grupo de campos recém-adicionado na matriz meta:extends e contém um $ref para o grupo de campos no atributo allOf.

{
    "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
    "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
    "meta:resourceType": "schemas",
    "version": "1.3",
    "title": "Loyalty Members",
    "type": "object",
    "description": "Information for all members of the loyalty program",
    "allOf": [
        {
            "$ref": "https://ns.adobe.com/xdm/context/profile",
            "type": "object",
            "meta:xdmType": "object"
        },
        {
            "$ref": "https://ns.adobe.com/xdm/context/profile-person-details",
            "type": "object",
            "meta:xdmType": "object"
        },
        {
            "$ref": "https://ns.adobe.com/xdm/context/profile-personal-details",
            "type": "object",
            "meta:xdmType": "object"
        },
        {
            "$ref": "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
            "type": "object",
            "meta:xdmType": "object"
        },
        {
            "$ref": "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
            "type": "object",
            "meta:xdmType": "object"
        }
    ],
    "refs": [
        "https://ns.adobe.com/xdm/context/profile-person-details",
        "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
        "https://ns.adobe.com/xdm/context/profile-personal-details",
        "https://ns.adobe.com/xdm/context/profile",
        "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691"
    ],
    "imsOrg": "{ORG_ID}",
    "meta:extensible": false,
    "meta:abstract": false,
    "meta:extends": [
        "https://ns.adobe.com/xdm/context/profile-person-details",
        "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
        "https://ns.adobe.com/xdm/context/profile-personal-details",
        "https://ns.adobe.com/xdm/common/auditable",
        "https://ns.adobe.com/xdm/data/record",
        "https://ns.adobe.com/xdm/context/profile",
        "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691"
    ],
    "meta:xdmType": "object",
    "meta:registryMetadata": {
        "repo:createdDate": 1673310304048,
        "repo:lastModifiedDate": 1673313118938,
        "xdm:createdClientId": "{CLIENT_ID}",
        "xdm:lastModifiedClientId": "{CLIENT_ID}",
        "xdm:createdUserId": "{USER_ID}",
        "xdm:lastModifiedUserId": "{USER_ID}",
        "eTag": "6559b197a04bb3fda5bc80bf383a260cfbe32539d528f0139c5750711eebfba2",
        "meta:globalLibVersion": "1.38.2"
    },
    "meta:class": "https://ns.adobe.com/xdm/context/profile",
    "meta:containerId": "tenant",
    "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
    "meta:sandboxType": "production",
    "meta:tenantNamespace": "_{TENANT_ID}",
    "meta:descriptorStatus": {
        "result": []
    }
}

Visualizar o esquema atual

Agora é possível executar uma solicitação GET para visualizar o esquema atual e ver como os grupos de campos adicionados contribuíram para a estrutura geral do esquema.

Formato da API

GET /tenant/schemas/{SCHEMA_ID}

Parâmetro

Descrição

{SCHEMA_ID}

O meta:altId ou o $id codificado na URL do esquema.

Solicitação

curl -X GET \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas/_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3 \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -H 'Accept: application/vnd.adobe.xed-full+json; version=1'

Resposta

Ao usar o cabeçalho application/vnd.adobe.xed-full+json; version=1 Accept, você pode ver o esquema completo mostrando todas as propriedades. Essas propriedades são os campos contribuídos pela classe e pelos grupos de campos que foram usados para compor o esquema. No exemplo de resposta abaixo, somente os campos adicionados recentemente são mostrados para fins de espaço. Você pode exibir o esquema completo, incluindo todas as propriedades e seus atributos, no apêndice ao final deste documento.

Em "properties", você pode ver o namespace _{TENANT_ID} que foi criado quando você adicionou o grupo de campos personalizados. Dentro desse namespace está o objeto loyaltyTier e os campos que foram definidos quando o grupo de campos foi criado.

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
  "meta:altId": "_{TENANT_ID}.mixins.9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
  "meta:resourceType": "mixins",
  "version": "1.0",
  "title": "Loyalty Tier",
  "type": "object",
  "description": "Captures info about the current loyalty tier of a customer.",
  "definitions": {
    "loyaltyTier": {
      "properties": {
        "_{TENANT_ID}": {
          "type": "object",
          "properties": {
            "loyaltyTier": {
              "type": "object",
              "properties": {
                "id": {
                  "title": "Loyalty Tier Identifier",
                  "type": "string",
                  "description": "Loyalty Tier Identifier.",
                  "meta:xdmType": "string"
                },
                "effectiveDate": {
                  "title": "Effective Date",
                  "type": "string",
                  "format": "date-time",
                  "description": "Date the member joined their current loyalty tier.",
                  "meta:xdmType": "date-time"
                },
                "currentThreshold": {
                  "title": "Current Point Threshold",
                  "type": "integer",
                  "description": "The minimum number of loyalty points the member must maintain to remain in the current tier.",
                  "meta:xdmType": "int"
                },
                "nextThreshold": {
                  "title": "Next Point Threshold",
                  "type": "integer",
                  "description": "The number of loyalty points the member must accrue to graduate to the next tier.",
                  "meta:xdmType": "int"
                }
              },
              "meta:xdmType": "object"
            }
          },
          "meta:xdmType": "object"
        }
      }
    }
  },
  "allOf": [
    {
      "$ref": "#/definitions/loyaltyTier",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": true,
  "meta:abstract": true,
  "meta:intendedToExtend": [
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673313004645,
    "repo:lastModifiedDate": 1673313004645,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "98e5d48808f5a4d9655493777389568a2581cfce013351ab9e1595d82f698dd6",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}"
}

Criar um tipo de dados

O grupo de campos Camada de Fidelidade criado contém propriedades específicas que podem ser úteis em outros esquemas. Por exemplo, os dados podem ser assimilados como parte de um evento de experiência ou usados por um esquema que implementa uma classe diferente. Nesse caso, faz sentido salvar a hierarquia de objetos como um tipo de dados para facilitar a reutilização da definição em outro lugar.

Os tipos de dados permitem definir uma hierarquia de objeto uma vez e fazer referência a ela em um campo, da mesma forma que faria para qualquer outro tipo escalar.

Em outras palavras, os tipos de dados permitem o uso consistente de estruturas de vários campos, com mais flexibilidade do que grupos de campos, pois podem ser incluídos em qualquer lugar de um esquema adicionando-os como o "tipo" de um campo.

Formato da API

POST /tenant/datatypes

Solicitação

A definição de um tipo de dados não requer campos meta:extends ou meta:intendedToExtend, e os campos não precisam ser aninhados na ID do locatário para evitar colisões.

curl -X POST \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/datatypes \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'Content-Type: application/json' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -d '{
        "title": "Loyalty Tier",
        "type": "object",
        "description": "Loyalty Tier data type",
        "definitions": {
          "loyaltyTier": {
            "type": "object",
            "properties": {
              "id": {
                "title": "Loyalty Tier Identifier",
                "type": "string",
                "description": "Loyalty Tier Identifier."
              },
              "effectiveDate": {
                "title": "Effective Date",
                "type": "string",
                "format": "date-time",
                "description": "Date the member joined their current loyalty tier."
              },
              "currentThreshold": {
                "title": "Current Point Threshold",
                "type": "integer",
                "description": "The minimum number of loyalty points the member must maintain to remain in the       current tier."
              },
              "nextThreshold": {
                "title": "Next Point Threshold",
                "type": "integer",
                "description": "The number of loyalty points the member must accrue to graduate to the next tier."
              }
            }
          }
        },
        "allOf": [
          {
            "$ref": "#/definitions/loyaltyTier"
          }
        ]
      }'

Resposta

Uma solicitação bem-sucedida retorna o Status de Resposta HTTP 201 (Criado) com um corpo de resposta contendo os detalhes do tipo de dados recém-criado, incluindo $id, meta:altIt e version. Esses valores são somente leitura e são atribuídos por Schema Registry.

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/datatypes/c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb",
  "meta:altId": "_{TENANT_ID}.datatypes.c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb",
  "meta:resourceType": "datatypes",
  "version": "1.0",
  "title": "Loyalty Tier",
  "type": "object",
  "description": "Loyalty Tier data type",
  "definitions": {
    "loyaltyTier": {
      "type": "object",
      "properties": {
        "id": {
          "title": "Loyalty Tier Identifier",
          "type": "string",
          "description": "Loyalty Tier Identifier.",
          "meta:xdmType": "string"
        },
        "effectiveDate": {
          "title": "Effective Date",
          "type": "string",
          "format": "date-time",
          "description": "Date the member joined their current loyalty tier.",
          "meta:xdmType": "date-time"
        },
        "currentThreshold": {
          "title": "Current Point Threshold",
          "type": "integer",
          "description": "The minimum number of loyalty points the member must maintain to remain in the current tier.",
          "meta:xdmType": "int"
        },
        "nextThreshold": {
          "title": "Next Point Threshold",
          "type": "integer",
          "description": "The number of loyalty points the member must accrue to graduate to the next tier.",
          "meta:xdmType": "int"
        }
      },
      "meta:xdmType": "object"
    }
  },
  "allOf": [
    {
      "$ref": "#/definitions/loyaltyTier",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": true,
  "meta:abstract": true,
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673378256699,
    "repo:lastModifiedDate": 1673378256699,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "8afba84c0c9a68126a7a1389f8523a1112bdf4405badc6dcddbbb4a0e18f5cdb",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}"
}

Você pode executar uma solicitação de pesquisa (GET) usando o URI $id codificado em URL para exibir o novo tipo de dados diretamente. Certifique-se de incluir o version em seu cabeçalho Accept para uma solicitação de pesquisa.

Usar tipo de dados no esquema

Agora que o tipo de dados Camada de Fidelidade foi criado, você pode atualizar (PATCH) o campo loyaltyTier no grupo de campos criado para fazer referência ao tipo de dados no lugar dos campos que estavam lá anteriormente.

Formato da API

PATCH /tenant/fieldgroups/{FIELD_GROUP_ID}

Parâmetro

Descrição

{FIELD_GROUP_ID}

O meta:altId ou a URL codificada $id do grupo de campos a ser atualizado.

Solicitação

curl -X PATCH \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/fieldgroups/_{TENANT_ID}.mixins.9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691 \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'Content-Type: application/json' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -d '[
        {
          "op": "replace",
          "path": "/definitions/loyaltyTier/properties/_{TENANT_ID}/properties",
          "value": {
            "loyaltyTier": {
              "title": "Loyalty Tier",
              "$ref": "https://ns.adobe.com/{TENANT_ID}/datatypes/c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb",
              "description": "Loyalty tier info"
            }
          }
        }
      ]'

Resposta

A resposta agora inclui uma referência ($ref) ao tipo de dados no objeto loyaltyTier em vez dos campos que foram definidos anteriormente.

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
  "meta:altId": "_{TENANT_ID}.mixins.9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
  "meta:resourceType": "mixins",
  "version": "1.1",
  "title": "Loyalty Tier",
  "type": "object",
  "description": "Captures info about the current loyalty tier of a customer.",
  "definitions": {
    "loyaltyTier": {
      "properties": {
        "_{TENANT_ID}": {
          "type": "object",
          "properties": {
            "loyaltyTier": {
              "title": "Loyalty Tier",
              "$ref": "https://ns.adobe.com/{TENANT_ID}/datatypes/c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb",
              "description": "Loyalty tier info",
              "type": "object",
              "meta:xdmType": "object"
            }
          },
          "meta:xdmType": "object"
        }
      }
    }
  },
  "allOf": [
    {
      "$ref": "#/definitions/loyaltyTier",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [
    "https://ns.adobe.com/{TENANT_ID}/datatypes/c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb"
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": true,
  "meta:abstract": true,
  "meta:intendedToExtend": [
    "https://ns.adobe.com/xdm/context/profile"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673313004645,
    "repo:lastModifiedDate": 1673378970276,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "4df8fa56d00991590364606bb2e219e1ea8f5717a51c0e6ae57ca956830b6a27",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}",
  "meta:descriptorStatus": {
    "result": []
  }
}

Se você executar uma solicitação GET para pesquisar o esquema agora, a propriedade loyaltyTier mostrará a referência ao tipo de dados em meta:referencedFrom:

"_{TENANT_ID}": {
  "type": "object",
  "meta:xdmType": "object",
  "properties": {
    "loyaltyTier": {
      "title": "Loyalty Tier",
      "description": "Loyalty tier info",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "id": {
          "title": "Loyalty Tier Identifier",
          "type": "string",
          "description": "Loyalty Tier Identifier.",
          "meta:xdmType": "string"
        },
        "effectiveDate": {
          "title": "Effective Date",
          "type": "string",
          "format": "date-time",
          "description": "Date the member joined their current loyalty tier.",
          "meta:xdmType": "date-time"
        },
        "currentThreshold": {
          "title": "Current Point Threshold",
          "type": "integer",
          "description": "The minimum number of loyalty points the member must maintain to remain in the current tier.",
          "meta:xdmType": "int"
        },
        "nextThreshold": {
          "title": "Next Point Threshold",
          "type": "integer",
          "description": "The number of loyalty points the member must accrue to graduate to the next tier.",
          "meta:xdmType": "int"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/{TENANT_ID}/datatypes/c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb"
    }
  }
}

Definir um descritor de identidade

Esquemas são usados para assimilar dados em Experience Platform. Esses dados são usados em vários serviços para criar uma visualização única e unificada de um indivíduo. Para ajudar nesse processo, os campos principais podem ser marcados como "Identidade" e, após a assimilação dos dados, os dados nesses campos são inseridos no "Gráfico de identidade" desse indivíduo. Os dados do gráfico podem ser acessados pelo Real-Time Customer Profile e por outros serviços do Experience Platform para fornecer uma visão unificada de cada cliente individual.

Os campos comumente marcados como "Identidade" incluem: endereço de email, número de telefone, Experience Cloud ID (ECID), ID de CRM ou outros campos de ID exclusivos. Considere quaisquer identificadores exclusivos específicos da sua organização, pois eles também podem ser bons campos de identidade.

Os descritores de identidade sinalizam que sourceProperty de sourceSchema é um identificador exclusivo que deve ser considerado uma identidade.

Para obter mais informações sobre como trabalhar com descritores, consulte o guia do desenvolvedor do Registro de Esquemas.

Formato da API

POST /tenant/descriptors

Solicitação

A solicitação a seguir define um descritor de identidade no campo personalEmail.address do esquema Membros de Fidelidade. Isso instrui Experience Platform a usar o endereço de email do membro do programa de fidelidade como um identificador para ajudar a unir informações sobre o indivíduo. Esta chamada também define este campo como a identidade principal do esquema, definindo xdm:isPrimary como true, que é um requisito para habilitar o esquema para uso no Perfil de Cliente em Tempo Real.

curl -X POST \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/descriptors \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'Content-Type: application/json' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -d '{
        "@type": "xdm:descriptorIdentity",
        "xdm:sourceSchema": "https://ns.adobe.com/{TENANT_ID}/schemas/533ca5da28087c44344810891b0f03d9",
        "xdm:sourceVersion": 1,
        "xdm:sourceProperty": "/_{TENANT_ID}/loyalty/loyaltyId",
        "xdm:namespace": "Email",
        "xdm:property": "xdm:code",
        "xdm:isPrimary": false
      }'

NOTE

Você pode listar valores "xdm:namespace" disponíveis ou criar novos, usando o Identity Service API. O valor de "xdm:property" pode ser "xdm:code" ou "xdm:id", dependendo do "xdm:namespace" usado.

Resposta

Uma resposta bem-sucedida retorna o Status HTTP 201 (Criado) com um corpo de resposta contendo os detalhes do descritor recém-criado, incluindo seu @id. @id é um campo somente leitura atribuído por Schema Registry e é usado para fazer referência ao descritor na API.

{
  "@id": "719a4391897c097786efbaa6d4262bb928a1cd88540344c6",
  "@type": "xdm:descriptorIdentity",
  "xdm:sourceSchema": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "xdm:sourceVersion": 1,
  "xdm:sourceProperty": "/personalEmail/address",
  "imsOrg": "{ORG_ID}",
  "version": "1",
  "xdm:namespace": "Email",
  "xdm:property": "xdm:code",
  "xdm:isPrimary": true,
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production"
}

Habilitar esquema para uso em Real-Time Customer Profile profile

Depois que o esquema tiver um descritor de identidade primário aplicado, você poderá habilitar o esquema Membros de Fidelidade para uso por Real-Time Customer Profile adicionando uma marca union ao atributo meta:immutableTags.

NOTE

Para obter mais informações sobre como trabalhar com exibições de união, consulte a seção sobre uniões no guia do desenvolvedor do Schema Registry.

Adicionar uma tag `union`

Para que um esquema seja incluído na exibição de união mesclada, a marca union deve ser adicionada ao atributo meta:immutableTags do esquema. Isso é feito por meio de uma solicitação PATCH para atualizar o esquema e adicionar uma matriz meta:immutableTags com um valor de union.

Formato da API

PATCH /tenant/schemas/{SCHEMA_ID}

Parâmetro

Descrição

{SCHEMA_ID}

O meta:altId ou o $id codificado na URL do esquema que você está habilitando para o Perfil.

Solicitação

curl -X PATCH \
  https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas/_{TENANT_ID}.schemas.533ca5da28087c44344810891b0f03d9 \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'Content-Type: application/json' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}' \
  -d '[
        { "op": "add", "path": "/meta:immutableTags", "value": ["union"]}
      ]'

Resposta

A resposta mostra que a operação foi executada com êxito e o esquema agora contém um atributo de nível superior, meta:immutableTags, que é uma matriz contendo o valor, "union".

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:resourceType": "schemas",
  "version": "1.4",
  "title": "Loyalty Members",
  "type": "object",
  "description": "Information for all members of the loyalty program",
  "allOf": [
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile-person-details",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/xdm/context/profile-personal-details",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
      "type": "object",
      "meta:xdmType": "object"
    },
    {
      "$ref": "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691",
      "type": "object",
      "meta:xdmType": "object"
    }
  ],
  "refs": [
    "https://ns.adobe.com/xdm/context/profile-person-details",
    "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
    "https://ns.adobe.com/xdm/context/profile-personal-details",
    "https://ns.adobe.com/xdm/context/profile",
    "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691"
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": false,
  "meta:abstract": false,
  "meta:extends": [
    "https://ns.adobe.com/xdm/context/profile-person-details",
    "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
    "https://ns.adobe.com/xdm/context/profile-personal-details",
    "https://ns.adobe.com/xdm/common/auditable",
    "https://ns.adobe.com/xdm/data/record",
    "https://ns.adobe.com/xdm/context/profile",
    "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673310304048,
    "repo:lastModifiedDate": 1673380280074,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "c590ccc7a293040d85c2b7d93276480ef4b4aa9a4fcd6991f50fbb47f58bced2",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:class": "https://ns.adobe.com/xdm/context/profile",
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}",
  "meta:immutableTags": [
    "union"
  ],
  "meta:descriptorStatus": {
    "result": []
  }
}

Listar esquemas em uma união

Você adicionou com êxito seu esquema à união XDM Individual Profile. Para ver uma lista de todos os esquemas que fazem parte da mesma união, você pode executar uma solicitação GET usando parâmetros de consulta para filtrar a resposta.

Usando o parâmetro de consulta property, você pode especificar que apenas esquemas contendo um campo meta:immutableTags que tenha um meta:class igual ao $id da classe XDM Individual Profile sejam retornados.

Formato da API

GET /tenant/schemas?property=meta:immutableTags==union&property=meta:class=={CLASS_ID}

Solicitação

A solicitação de exemplo abaixo retorna todos os esquemas que fazem parte da união XDM Individual Profile.

curl -X GET \
  'https://platform.adobe.io/data/foundation/schemaregistry/tenant/schemas?property=meta:immutableTags==union&property=meta:class==https://ns.adobe.com/xdm/context/profile' \
  -H 'Accept: application/vnd.adobe.xed-id+json' \
  -H 'Authorization: Bearer {ACCESS_TOKEN}' \
  -H 'x-api-key: {API_KEY}' \
  -H 'x-gw-ims-org-id: {ORG_ID}' \
  -H 'x-sandbox-name: {SANDBOX_NAME}'

Resposta

A resposta é uma lista filtrada de esquemas, contendo apenas aqueles que atendem a ambos os requisitos. Lembre-se de que, ao usar vários parâmetros de consulta, uma relação AND é presumida. O formato da resposta da lista depende do cabeçalho Accept enviado na solicitação.

{
  "results": [
    {
      "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/d29a200b5deb6cfb55d3b865ef627f33",
      "meta:altId": "_{TENANT_ID}.schemas.d29a200b5deb6cfb55d3b865ef627f33",
      "version": "1.2",
      "title": "Profile Schema"
    },
    {
      "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/5d70026f5522fc60b3c81f6523b83c86",
      "meta:altId": "_{TENANT_ID}.schemas.5d70026f5522fc60b3c81f6523b83c86",
      "version": "1.3",
      "title": "CRM Onboarding"
    },
    {
      "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/653e53eb04341d09453c9b6a5fb43d1b4ca9526ec274856d",
      "meta:altId": "_{TENANT_ID}.schemas.653e53eb04341d09453c9b6a5fb43d1b4ca9526ec274856d",
      "version": "1.1",
      "title": "Profile consents"
    },
    {
      "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
      "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
      "version": "1.4",
      "title": "Loyalty Members"
    }
  ],
  "_page": {
    "orderby": "updated",
    "next": null,
    "count": 4
  },
  "_links": {
    "next": null,
    "global_schemas": {
      "href": "https://platform.adobe.io/data/foundation/schemaregistry/global/schemas?property=meta:immutableTags==union&property=meta:class==https://ns.adobe.com/xdm/context/profile"
    }
  }
}

Próximas etapas

Ao seguir este tutorial, você compôs um esquema com sucesso usando grupos de campos padrão e um grupo de campos definido. Agora você pode usar esse esquema para criar um conjunto de dados e assimilar dados de registro na Adobe Experience Platform.

O esquema Membros de fidelidade completo, conforme criado neste tutorial, está disponível no apêndice a seguir. Ao observar o esquema, é possível ver como os grupos de campos contribuem para a estrutura geral e quais campos estão disponíveis para assimilação de dados.

Depois de criar mais de um schema, você pode definir os relacionamentos entre eles usando descritores de relacionamento. Consulte o tutorial para definindo uma relação entre dois esquemas para obter mais informações. Para obter exemplos detalhados de como executar todas as operações (GET, POST, PUT, PATCH e DELETE) no registro, consulte o guia do desenvolvedor do Registro de Esquemas enquanto trabalha com a API.

Apêndice appendix

As informações a seguir complementam o tutorial sobre a API.

Concluir esquema de Membros de Fidelidade complete-schema

Neste tutorial, um esquema é composto para descrever os membros de um programa de fidelidade de varejo.

O esquema implementa a classe XDM Individual Profile e combina vários grupos de campos. Captura informações sobre os membros de fidelidade usando os grupos de campos padrão Demographic Details, Detalhes de Contato Pessoal e Detalhes de Fidelidade, bem como por meio de um grupo de campos Camada de Fidelidade personalizado definido durante o tutorial.

O esquema a seguir mostra o esquema Membros de Fidelidade concluído no formato JSON:

Exibir esquema completo

code language-json

code language-json
{ "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3", "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3", "meta:resourceType": "schemas", "version": "1.4", "title": "Loyalty Members", "type": "object", "description": "Information for all members of the loyalty program", "properties": { "_{TENANT_ID}": { "type": "object", "properties": { "loyaltyTier": { "title": "Loyalty Tier", "description": "Loyalty tier info", "type": "object", "meta:xdmType": "object", "properties": { "id": { "title": "Loyalty Tier Identifier", "type": "string", "description": "Loyalty Tier Identifier.", "meta:xdmType": "string" }, "effectiveDate": { "title": "Effective Date", "type": "string", "format": "date-time", "description": "Date the member joined their current loyalty tier.", "meta:xdmType": "date-time" }, "currentThreshold": { "title": "Current Point Threshold", "type": "integer", "description": "The minimum number of loyalty points the member must maintain to remain in the current tier.", "meta:xdmType": "int" }, "nextThreshold": { "title": "Next Point Threshold", "type": "integer", "description": "The number of loyalty points the member must accrue to graduate to the next tier.", "meta:xdmType": "int" } }, "meta:referencedFrom": "https://ns.adobe.com/{TENANT_ID}/datatypes/c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb" } }, "meta:xdmType": "object" }, "_id": { "title": "Identifier", "type": "string", "format": "uri-reference", "description": "A unique identifier for the record.", "meta:xdmType": "string", "meta:xdmField": "@id" }, "_repo": { "properties": { "createDate": { "type": "string", "format": "date-time", "meta:immutable": true, "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:createDate" }, "modifyDate": { "type": "string", "format": "date-time", "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:modifyDate" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "billingAddress": { "title": "Billing Address", "description": "Billing postal address.", "type": "object", "meta:xdmType": "object", "properties": { "_id": { "title": "Coordinates ID", "type": "string", "format": "uri-reference", "description": "The unique identifier of the coordinates.", "meta:xdmType": "string", "meta:xdmField": "@id" }, "_repo": { "properties": { "createDate": { "type": "string", "format": "date-time", "meta:immutable": true, "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:createDate" }, "modifyDate": { "type": "string", "format": "date-time", "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:modifyDate" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "_schema": { "properties": { "description": { "title": "Description", "type": "string", "description": "A description of what the coordinates identify.", "meta:xdmType": "string", "meta:xdmField": "schema:description" }, "elevation": { "title": "Elevation", "type": "number", "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.", "meta:xdmType": "number", "meta:xdmField": "schema:elevation" }, "latitude": { "title": "Latitude", "type": "number", "minimum": -90, "maximum": 90, "description": "The signed vertical coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:latitude" }, "longitude": { "title": "Longitude", "type": "number", "minimum": -180, "maximum": 180, "description": "The signed horizontal coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:longitude" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "city": { "title": "City", "type": "string", "description": "The name of the city.", "meta:xdmType": "string", "meta:xdmField": "xdm:city" }, "country": { "title": "Country", "type": "string", "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.", "meta:xdmType": "string", "meta:xdmField": "xdm:country" }, "countryCode": { "title": "Country code", "type": "string", "pattern": "^[A-Z]{2}$", "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.", "meta:xdmType": "string", "meta:xdmField": "xdm:countryCode" }, "createdByBatchID": { "title": "Created by batch identifier", "type": "string", "format": "uri-reference", "description": "The dataset files in Catalog which has been originating the creation of the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:createdByBatchID" }, "dmaID": { "title": "Designated market area", "type": "integer", "description": "The Nielsen media research designated market area.", "meta:xdmType": "int", "meta:xdmField": "xdm:dmaID" }, "label": { "title": "Label", "type": "string", "description": "Free form name of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:label" }, "lastVerifiedDate": { "title": "Last verified date", "type": "string", "format": "date", "description": "The date that the address was last verified as still associated to the person.", "meta:xdmType": "date", "meta:xdmField": "xdm:lastVerifiedDate" }, "modifiedByBatchID": { "title": "Modified by batch identifier", "type": "string", "format": "uri-reference", "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.", "meta:xdmType": "string", "meta:xdmField": "xdm:modifiedByBatchID" }, "msaID": { "title": "Metropolitan statistical area", "type": "integer", "description": "The metropolitan statistical area in the United States where the observation occurred.", "meta:xdmType": "int", "meta:xdmField": "xdm:msaID" }, "postOfficeBox": { "title": "Post office box", "type": "string", "description": "Post office box of the address.", "maxLength": 20, "meta:xdmType": "string", "meta:xdmField": "xdm:postOfficeBox" }, "postalCode": { "title": "Postal code", "type": "string", "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.", "meta:xdmType": "string", "meta:xdmField": "xdm:postalCode" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "region": { "title": "Region", "type": "string", "description": "The region, county, or district portion of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:region" }, "repositoryCreatedBy": { "title": "Created by user identifier", "type": "string", "description": "User ID of who created the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryCreatedBy" }, "repositoryLastModifiedBy": { "title": "Modified by user identifier", "type": "string", "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryLastModifiedBy" }, "state": { "title": "State", "type": "string", "description": "The name of the State. This is a free-form field.", "meta:xdmType": "string", "meta:xdmField": "xdm:state" }, "stateProvince": { "title": "State or province", "type": "string", "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.", "examples": [ "US-CA", "DE-BB", "JP-13" ], "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}\|)", "meta:xdmType": "string", "meta:xdmField": "xdm:stateProvince" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the address.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "pending_verification": "Pending verification", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "street1": { "title": "Street 1", "type": "string", "description": "Primary street level information, apartment number, street number, and street name.", "meta:xdmType": "string", "meta:xdmField": "xdm:street1" }, "street2": { "title": "Street 2", "type": "string", "description": "Optional street information second line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street2" }, "street3": { "title": "Street 3", "type": "string", "description": "Optional street information third line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street3" }, "street4": { "title": "Street 4", "type": "string", "description": "Optional street information fourth line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street4" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address", "meta:xdmField": "xdm:billingAddress" }, "createdByBatchID": { "title": "Created by batch identifier", "type": "string", "format": "uri-reference", "description": "The dataset files in Catalog which has been originating the creation of the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:createdByBatchID" }, "faxPhone": { "title": "Fax Phone", "description": "Fax phone number.", "type": "object", "meta:xdmType": "object", "properties": { "countryCode": { "title": "Country Calling Code", "type": "string", "description": "Country calling code (CC) as defined by E.164.", "minLength": 1, "maxLength": 3, "pattern": "^[0-9]{1,3}?$", "meta:xdmType": "string", "meta:xdmField": "xdm:countryCode" }, "extension": { "title": "Extension", "type": "string", "description": "The internal dialing number used to call from a private exchange, operator, or switchboard.", "meta:xdmType": "string", "meta:xdmField": "xdm:extension" }, "number": { "title": "Number", "type": "string", "description": "The phone number. Note the phone number is a string and may include meaningful characters such as brackets '()', hyphens '-', or characters to indicate sub-dialing identifiers like extensions 'x' for example, 1-353(0)18391111 or +613 9403600x1234.", "meta:xdmType": "string", "meta:xdmField": "xdm:number" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary phone number indicator. Unlike address or email address, there can be multiple primary phone numbers; one per communication channel. The communication channel is defined by the type: `textMessaging`, `mobile`, `phone`, `home`, `work`, `unknown`, and `fax`.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the phone number.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "validity": { "title": "Validity", "type": "string", "description": "A level of technical correctness of the phone number.", "meta:enum": { "consistent": "Consistent", "inconsistent": "Inconsistent", "incomplete": "Incomplete", "successfullyUsed": "Successfully used" }, "meta:xdmType": "string", "meta:xdmField": "xdm:validity" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/context/phonenumber", "meta:xdmField": "xdm:faxPhone" }, "homeAddress": { "title": "Home Address", "description": "A home postal address.", "type": "object", "meta:xdmType": "object", "properties": { "_id": { "title": "Coordinates ID", "type": "string", "format": "uri-reference", "description": "The unique identifier of the coordinates.", "meta:xdmType": "string", "meta:xdmField": "@id" }, "_repo": { "properties": { "createDate": { "type": "string", "format": "date-time", "meta:immutable": true, "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:createDate" }, "modifyDate": { "type": "string", "format": "date-time", "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:modifyDate" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "_schema": { "properties": { "description": { "title": "Description", "type": "string", "description": "A description of what the coordinates identify.", "meta:xdmType": "string", "meta:xdmField": "schema:description" }, "elevation": { "title": "Elevation", "type": "number", "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.", "meta:xdmType": "number", "meta:xdmField": "schema:elevation" }, "latitude": { "title": "Latitude", "type": "number", "minimum": -90, "maximum": 90, "description": "The signed vertical coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:latitude" }, "longitude": { "title": "Longitude", "type": "number", "minimum": -180, "maximum": 180, "description": "The signed horizontal coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:longitude" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "city": { "title": "City", "type": "string", "description": "The name of the city.", "meta:xdmType": "string", "meta:xdmField": "xdm:city" }, "country": { "title": "Country", "type": "string", "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.", "meta:xdmType": "string", "meta:xdmField": "xdm:country" }, "countryCode": { "title": "Country code", "type": "string", "pattern": "^[A-Z]{2}$", "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.", "meta:xdmType": "string", "meta:xdmField": "xdm:countryCode" }, "createdByBatchID": { "title": "Created by batch identifier", "type": "string", "format": "uri-reference", "description": "The dataset files in Catalog which has been originating the creation of the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:createdByBatchID" }, "dmaID": { "title": "Designated market area", "type": "integer", "description": "The Nielsen media research designated market area.", "meta:xdmType": "int", "meta:xdmField": "xdm:dmaID" }, "label": { "title": "Label", "type": "string", "description": "Free form name of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:label" }, "lastVerifiedDate": { "title": "Last verified date", "type": "string", "format": "date", "description": "The date that the address was last verified as still associated to the person.", "meta:xdmType": "date", "meta:xdmField": "xdm:lastVerifiedDate" }, "modifiedByBatchID": { "title": "Modified by batch identifier", "type": "string", "format": "uri-reference", "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.", "meta:xdmType": "string", "meta:xdmField": "xdm:modifiedByBatchID" }, "msaID": { "title": "Metropolitan statistical area", "type": "integer", "description": "The metropolitan statistical area in the United States where the observation occurred.", "meta:xdmType": "int", "meta:xdmField": "xdm:msaID" }, "postOfficeBox": { "title": "Post office box", "type": "string", "description": "Post office box of the address.", "maxLength": 20, "meta:xdmType": "string", "meta:xdmField": "xdm:postOfficeBox" }, "postalCode": { "title": "Postal code", "type": "string", "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.", "meta:xdmType": "string", "meta:xdmField": "xdm:postalCode" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "region": { "title": "Region", "type": "string", "description": "The region, county, or district portion of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:region" }, "repositoryCreatedBy": { "title": "Created by user identifier", "type": "string", "description": "User ID of who created the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryCreatedBy" }, "repositoryLastModifiedBy": { "title": "Modified by user identifier", "type": "string", "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryLastModifiedBy" }, "state": { "title": "State", "type": "string", "description": "The name of the State. This is a free-form field.", "meta:xdmType": "string", "meta:xdmField": "xdm:state" }, "stateProvince": { "title": "State or province", "type": "string", "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.", "examples": [ "US-CA", "DE-BB", "JP-13" ], "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}\|)", "meta:xdmType": "string", "meta:xdmField": "xdm:stateProvince" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the address.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "pending_verification": "Pending verification", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "street1": { "title": "Street 1", "type": "string", "description": "Primary street level information, apartment number, street number, and street name.", "meta:xdmType": "string", "meta:xdmField": "xdm:street1" }, "street2": { "title": "Street 2", "type": "string", "description": "Optional street information second line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street2" }, "street3": { "title": "Street 3", "type": "string", "description": "Optional street information third line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street3" }, "street4": { "title": "Street 4", "type": "string", "description": "Optional street information fourth line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street4" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address", "meta:xdmField": "xdm:homeAddress" }, "homePhone": { "title": "Home Phone", "description": "Home phone number.", "type": "object", "meta:xdmType": "object", "properties": { "countryCode": { "title": "Country Calling Code", "type": "string", "description": "Country calling code (CC) as defined by E.164.", "minLength": 1, "maxLength": 3, "pattern": "^[0-9]{1,3}?$", "meta:xdmType": "string", "meta:xdmField": "xdm:countryCode" }, "extension": { "title": "Extension", "type": "string", "description": "The internal dialing number used to call from a private exchange, operator, or switchboard.", "meta:xdmType": "string", "meta:xdmField": "xdm:extension" }, "number": { "title": "Number", "type": "string", "description": "The phone number. Note the phone number is a string and may include meaningful characters such as brackets '()', hyphens '-', or characters to indicate sub-dialing identifiers like extensions 'x' for example, 1-353(0)18391111 or +613 9403600x1234.", "meta:xdmType": "string", "meta:xdmField": "xdm:number" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary phone number indicator. Unlike address or email address, there can be multiple primary phone numbers; one per communication channel. The communication channel is defined by the type: `textMessaging`, `mobile`, `phone`, `home`, `work`, `unknown`, and `fax`.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the phone number.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "validity": { "title": "Validity", "type": "string", "description": "A level of technical correctness of the phone number.", "meta:enum": { "consistent": "Consistent", "inconsistent": "Inconsistent", "incomplete": "Incomplete", "successfullyUsed": "Successfully used" }, "meta:xdmType": "string", "meta:xdmField": "xdm:validity" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/context/phonenumber", "meta:xdmField": "xdm:homePhone" }, "loyalty": { "type": "object", "description": "Captures details related to the customer's loyalty rewards.", "properties": { "joinDate": { "title": "Program Join Date", "type": "string", "format": "date-time", "description": "Date which the visitor registered for the loyalty program.", "meta:xdmType": "date-time", "meta:xdmField": "xdm:joinDate" }, "loyaltyID": { "title": "Program ID", "type": "array", "items": { "type": "string", "meta:xdmType": "string" }, "description": "The loyalty program ID(s) associated with a specific user, if they are enrolled in the client's loyalty program.", "meta:xdmType": "array", "meta:xdmField": "xdm:loyaltyID" }, "points": { "title": "Program Points Balance", "type": "number", "description": "Current balance of the loyalty points/awards in a visitor's loyalty account.", "meta:xdmType": "number", "meta:xdmField": "xdm:points" }, "pointsExpiration": { "title": "Points Expiration", "type": "array", "items": { "type": "object", "properties": { "pointsExpirationDate": { "type": "string", "format": "date-time", "description": "Date on which the given portion of the loyalty points expire.", "meta:xdmType": "date-time", "meta:xdmField": "xdm:pointsExpirationDate" }, "pointsExpiring": { "title": "Points Expiring", "type": "number", "description": "Point balance expiring as of the associated expiration date.", "meta:xdmType": "number", "meta:xdmField": "xdm:pointsExpiring" } }, "meta:xdmType": "object" }, "meta:xdmType": "array", "meta:xdmField": "xdm:pointsExpiration" }, "pointsRedeemed": { "title": "Points Redeemed", "type": "number", "description": "Amount of points applied toward a purchase or otherwise redeemed.", "meta:xdmType": "number", "meta:xdmField": "xdm:pointsRedeemed" }, "program": { "title": "Program Name", "type": "string", "description": "This should define the loyalty progam in which a visitor is enrolled.", "meta:xdmType": "string", "meta:xdmField": "xdm:program" }, "status": { "title": "Status", "type": "string", "description": "Captures the visitor's loyalty progam status, such as active, disabled, or suspended.", "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "tier": { "title": "Tier", "type": "string", "description": "Captures the loyalty progam tier in which a visitor is enrolled.", "meta:xdmType": "string", "meta:xdmField": "xdm:tier" }, "upgradeDate": { "title": "Program Name", "type": "string", "description": "Date which the customer was upgraded to the next tier level.", "meta:xdmType": "string", "meta:xdmField": "xdm:upgradeDate" } }, "meta:xdmType": "object", "meta:xdmField": "xdm:loyalty" }, "mailingAddress": { "title": "Mailing Address", "description": "Mailing postal address.", "type": "object", "meta:xdmType": "object", "properties": { "_id": { "title": "Coordinates ID", "type": "string", "format": "uri-reference", "description": "The unique identifier of the coordinates.", "meta:xdmType": "string", "meta:xdmField": "@id" }, "_repo": { "properties": { "createDate": { "type": "string", "format": "date-time", "meta:immutable": true, "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:createDate" }, "modifyDate": { "type": "string", "format": "date-time", "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:modifyDate" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "_schema": { "properties": { "description": { "title": "Description", "type": "string", "description": "A description of what the coordinates identify.", "meta:xdmType": "string", "meta:xdmField": "schema:description" }, "elevation": { "title": "Elevation", "type": "number", "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.", "meta:xdmType": "number", "meta:xdmField": "schema:elevation" }, "latitude": { "title": "Latitude", "type": "number", "minimum": -90, "maximum": 90, "description": "The signed vertical coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:latitude" }, "longitude": { "title": "Longitude", "type": "number", "minimum": -180, "maximum": 180, "description": "The signed horizontal coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:longitude" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "city": { "title": "City", "type": "string", "description": "The name of the city.", "meta:xdmType": "string", "meta:xdmField": "xdm:city" }, "country": { "title": "Country", "type": "string", "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.", "meta:xdmType": "string", "meta:xdmField": "xdm:country" }, "countryCode": { "title": "Country code", "type": "string", "pattern": "^[A-Z]{2}$", "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.", "meta:xdmType": "string", "meta:xdmField": "xdm:countryCode" }, "createdByBatchID": { "title": "Created by batch identifier", "type": "string", "format": "uri-reference", "description": "The dataset files in Catalog which has been originating the creation of the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:createdByBatchID" }, "dmaID": { "title": "Designated market area", "type": "integer", "description": "The Nielsen media research designated market area.", "meta:xdmType": "int", "meta:xdmField": "xdm:dmaID" }, "label": { "title": "Label", "type": "string", "description": "Free form name of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:label" }, "lastVerifiedDate": { "title": "Last verified date", "type": "string", "format": "date", "description": "The date that the address was last verified as still associated to the person.", "meta:xdmType": "date", "meta:xdmField": "xdm:lastVerifiedDate" }, "modifiedByBatchID": { "title": "Modified by batch identifier", "type": "string", "format": "uri-reference", "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.", "meta:xdmType": "string", "meta:xdmField": "xdm:modifiedByBatchID" }, "msaID": { "title": "Metropolitan statistical area", "type": "integer", "description": "The metropolitan statistical area in the United States where the observation occurred.", "meta:xdmType": "int", "meta:xdmField": "xdm:msaID" }, "postOfficeBox": { "title": "Post office box", "type": "string", "description": "Post office box of the address.", "maxLength": 20, "meta:xdmType": "string", "meta:xdmField": "xdm:postOfficeBox" }, "postalCode": { "title": "Postal code", "type": "string", "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.", "meta:xdmType": "string", "meta:xdmField": "xdm:postalCode" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "region": { "title": "Region", "type": "string", "description": "The region, county, or district portion of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:region" }, "repositoryCreatedBy": { "title": "Created by user identifier", "type": "string", "description": "User ID of who created the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryCreatedBy" }, "repositoryLastModifiedBy": { "title": "Modified by user identifier", "type": "string", "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryLastModifiedBy" }, "state": { "title": "State", "type": "string", "description": "The name of the State. This is a free-form field.", "meta:xdmType": "string", "meta:xdmField": "xdm:state" }, "stateProvince": { "title": "State or province", "type": "string", "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.", "examples": [ "US-CA", "DE-BB", "JP-13" ], "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}\|)", "meta:xdmType": "string", "meta:xdmField": "xdm:stateProvince" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the address.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "pending_verification": "Pending verification", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "street1": { "title": "Street 1", "type": "string", "description": "Primary street level information, apartment number, street number, and street name.", "meta:xdmType": "string", "meta:xdmField": "xdm:street1" }, "street2": { "title": "Street 2", "type": "string", "description": "Optional street information second line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street2" }, "street3": { "title": "Street 3", "type": "string", "description": "Optional street information third line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street3" }, "street4": { "title": "Street 4", "type": "string", "description": "Optional street information fourth line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street4" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address", "meta:xdmField": "xdm:mailingAddress" }, "mobilePhone": { "title": "Mobile Phone", "description": "Mobile phone number.", "type": "object", "meta:xdmType": "object", "properties": { "countryCode": { "title": "Country Calling Code", "type": "string", "description": "Country calling code (CC) as defined by E.164.", "minLength": 1, "maxLength": 3, "pattern": "^[0-9]{1,3}?$", "meta:xdmType": "string", "meta:xdmField": "xdm:countryCode" }, "extension": { "title": "Extension", "type": "string", "description": "The internal dialing number used to call from a private exchange, operator, or switchboard.", "meta:xdmType": "string", "meta:xdmField": "xdm:extension" }, "number": { "title": "Number", "type": "string", "description": "The phone number. Note the phone number is a string and may include meaningful characters such as brackets '()', hyphens '-', or characters to indicate sub-dialing identifiers like extensions 'x' for example, 1-353(0)18391111 or +613 9403600x1234.", "meta:xdmType": "string", "meta:xdmField": "xdm:number" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary phone number indicator. Unlike address or email address, there can be multiple primary phone numbers; one per communication channel. The communication channel is defined by the type: `textMessaging`, `mobile`, `phone`, `home`, `work`, `unknown`, and `fax`.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the phone number.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "validity": { "title": "Validity", "type": "string", "description": "A level of technical correctness of the phone number.", "meta:enum": { "consistent": "Consistent", "inconsistent": "Inconsistent", "incomplete": "Incomplete", "successfullyUsed": "Successfully used" }, "meta:xdmType": "string", "meta:xdmField": "xdm:validity" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/context/phonenumber", "meta:xdmField": "xdm:mobilePhone" }, "modifiedByBatchID": { "title": "Modified by batch identifier", "type": "string", "format": "uri-reference", "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.", "meta:xdmType": "string", "meta:xdmField": "xdm:modifiedByBatchID" }, "person": { "title": "Person", "description": "An individual actor, contact, or owner.", "type": "object", "meta:xdmType": "object", "properties": { "birthDate": { "title": "Birth date(YYYY-MM-DD)", "type": "string", "format": "date", "description": "The full date a person was born.", "meta:xdmType": "date", "meta:xdmField": "xdm:birthDate" }, "birthDayAndMonth": { "title": "Birth date (MM-DD)", "type": "string", "pattern": "[0-1][0-9]-[0-9][0-9]", "description": "The day and month a person was born, in the format MM-DD. This field should be used when the day and month of a person's birth is known, but not the year.", "meta:xdmType": "string", "meta:xdmField": "xdm:birthDayAndMonth" }, "birthYear": { "title": "Birth year", "type": "integer", "description": "The year a person was born including the century, for example, 1983. This field should be used when only the person's age is known, not the full birth date.", "minimum": 1, "maximum": 32767, "meta:xdmType": "short", "meta:xdmField": "xdm:birthYear" }, "gender": { "title": "Gender", "type": "string", "enum": [ "male", "female", "not_specified", "non_specific" ], "meta:enum": { "male": "Male", "female": "Female", "not_specified": "Not Specified", "non_specific": "Non-specific" }, "description": "Gender identity of the person.\n", "default": "not_specified", "meta:xdmType": "string", "meta:xdmField": "xdm:gender" }, "maritalStatus": { "title": "Marital Status", "type": "string", "enum": [ "married", "single", "divorced", "widowed", "not_specified" ], "meta:enum": { "married": "Married", "single": "Single", "divorced": "Divorced", "widowed": "Widowed", "not_specified": "Not Specified" }, "description": "Describes a person's relationship with a significant other.", "default": "not_specified", "meta:xdmType": "string", "meta:xdmField": "xdm:maritalStatus" }, "name": { "title": "Full name", "description": "The person's full name.", "type": "object", "meta:xdmType": "object", "properties": { "courtesyTitle": { "title": "Courtesy title", "type": "string", "description": "Normally an abbreviation of a persons title, honorific, or salutation. The `courtesyTitle` is used in front of full or last name in opening texts. For example, Mr. Miss. or Dr.", "meta:xdmType": "string", "meta:xdmField": "xdm:courtesyTitle" }, "firstName": { "title": "First name", "type": "string", "description": "The first segment of the name in the writing order most commonly accepted in the language of the name. In many cultures this is the preferred personal or given name. The `firstName` and `lastName` properties have been introduced to maintain compatibility with existing systems that model names in a simplified, non-semantic, and non-internationalizable way. Using `xdm:fullName` is always preferable.", "meta:xdmType": "string", "meta:xdmField": "xdm:firstName" }, "fullName": { "title": "Full name", "type": "string", "description": "The full name of the person, in writing order most commonly accepted in the language of the name.", "meta:xdmType": "string", "meta:xdmField": "xdm:fullName" }, "lastName": { "title": "Last name", "type": "string", "description": "The last segment of the name in the writing order most commonly accepted in the language of the name. In many cultures this is the inherited family name, surname, patronymic, or matronymic name. The `firstName` and `lastName` properties have been introduced to maintain compatibility with existing systems that model names in a simplified, non-semantic, and non-internationalizable way. Using `xdm:fullName` is always preferable.", "meta:xdmType": "string", "meta:xdmField": "xdm:lastName" }, "middleName": { "title": "Middle name", "type": "string", "description": "Middle, alternative, or additional names supplied between the first name and last name.", "meta:xdmType": "string", "meta:xdmField": "xdm:middleName" }, "suffix": { "title": "Suffix", "type": "string", "description": "A group of letters provided after a person's name to provide additional information. The `suffix` is used at the end of someones name. For example Jr., Sr., M.D., PhD, I, II, III, etc.", "meta:xdmType": "string", "meta:xdmField": "xdm:suffix" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/context/person-name", "meta:xdmField": "xdm:name" }, "nationality": { "title": "Nationality", "type": "string", "pattern": "^[A-Z]{2}$", "description": "The legal relationship between a person and their state represented using the ISO 3166-1 Alpha-2 code.", "meta:xdmType": "string", "meta:xdmField": "xdm:nationality" }, "taxId": { "title": "Tax ID", "type": "string", "description": "The Tax / Fiscal ID of the person, e.g. the TIN in the US or the CIF/NIF in Spain.", "meta:status": "deprecated", "meta:xdmType": "string", "meta:xdmField": "xdm:taxId" }, "type": { "title": "Type", "type": "string", "description": "The type of individual in different business contexts like B2C.", "meta:xdmType": "string", "meta:xdmField": "xdm:type" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/context/person", "meta:xdmField": "xdm:person" }, "personID": { "title": "Person ID", "description": "Unique identifier of Person/Profile fragment.", "type": "string", "meta:xdmType": "string", "meta:xdmField": "xdm:personID" }, "personalEmail": { "title": "Personal Email", "description": "A personal email address.", "type": "object", "meta:xdmType": "object", "properties": { "address": { "title": "Address", "type": "string", "format": "email", "description": "The technical address, for example, 'name@domain.com' as commonly defined in RFC2822 and subsequent standards.", "meta:xdmType": "string", "meta:xdmField": "xdm:address", "minLength": 1 }, "label": { "title": "Label", "type": "string", "description": "Additional display information that maybe available, for example, Microsoft Outlook rich address controls display 'John Smith smithjr@company.uk', 'John Smith' part is data that would be placed in the label.", "meta:xdmType": "string", "meta:xdmField": "xdm:label" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary email indicator. A profile can have only one `primary` email address at a given point of time.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the email address.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "pending_verification": "Pending verification", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "type": { "title": "Type", "type": "string", "description": "The way the account relates to the person for example 'work' or 'personal'.", "meta:enum": { "unknown": "Unknown", "personal": "Personal", "work": "Work", "education": "Education" }, "meta:xdmType": "string", "meta:xdmField": "xdm:type" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/context/emailaddress", "meta:xdmField": "xdm:personalEmail", "required": [ "address" ] }, "repositoryCreatedBy": { "title": "Created by user identifier", "type": "string", "description": "User ID of who created the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryCreatedBy" }, "repositoryLastModifiedBy": { "title": "Modified by user identifier", "type": "string", "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryLastModifiedBy" }, "shippingAddress": { "title": "Shipping Address", "description": "Shipping postal address.", "type": "object", "meta:xdmType": "object", "properties": { "_id": { "title": "Coordinates ID", "type": "string", "format": "uri-reference", "description": "The unique identifier of the coordinates.", "meta:xdmType": "string", "meta:xdmField": "@id" }, "_repo": { "properties": { "createDate": { "type": "string", "format": "date-time", "meta:immutable": true, "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:createDate" }, "modifyDate": { "type": "string", "format": "date-time", "meta:usereditable": false, "examples": [ "2004-10-23T12:00:00-06:00" ], "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".", "meta:xdmType": "date-time", "meta:xdmField": "repo:modifyDate" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "_schema": { "properties": { "description": { "title": "Description", "type": "string", "description": "A description of what the coordinates identify.", "meta:xdmType": "string", "meta:xdmField": "schema:description" }, "elevation": { "title": "Elevation", "type": "number", "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.", "meta:xdmType": "number", "meta:xdmField": "schema:elevation" }, "latitude": { "title": "Latitude", "type": "number", "minimum": -90, "maximum": 90, "description": "The signed vertical coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:latitude" }, "longitude": { "title": "Longitude", "type": "number", "minimum": -180, "maximum": 180, "description": "The signed horizontal coordinate of a geographic point.", "meta:xdmType": "number", "meta:xdmField": "schema:longitude" } }, "type": "object", "meta:xdmType": "object", "meta:xedConverted": true }, "city": { "title": "City", "type": "string", "description": "The name of the city.", "meta:xdmType": "string", "meta:xdmField": "xdm:city" }, "country": { "title": "Country", "type": "string", "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.", "meta:xdmType": "string", "meta:xdmField": "xdm:country" }, "countryCode": { "title": "Country code", "type": "string", "pattern": "^[A-Z]{2}$", "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.", "meta:xdmType": "string", "meta:xdmField": "xdm:countryCode" }, "createdByBatchID": { "title": "Created by batch identifier", "type": "string", "format": "uri-reference", "description": "The dataset files in Catalog which has been originating the creation of the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:createdByBatchID" }, "dmaID": { "title": "Designated market area", "type": "integer", "description": "The Nielsen media research designated market area.", "meta:xdmType": "int", "meta:xdmField": "xdm:dmaID" }, "label": { "title": "Label", "type": "string", "description": "Free form name of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:label" }, "lastVerifiedDate": { "title": "Last verified date", "type": "string", "format": "date", "description": "The date that the address was last verified as still associated to the person.", "meta:xdmType": "date", "meta:xdmField": "xdm:lastVerifiedDate" }, "modifiedByBatchID": { "title": "Modified by batch identifier", "type": "string", "format": "uri-reference", "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.", "meta:xdmType": "string", "meta:xdmField": "xdm:modifiedByBatchID" }, "msaID": { "title": "Metropolitan statistical area", "type": "integer", "description": "The metropolitan statistical area in the United States where the observation occurred.", "meta:xdmType": "int", "meta:xdmField": "xdm:msaID" }, "postOfficeBox": { "title": "Post office box", "type": "string", "description": "Post office box of the address.", "maxLength": 20, "meta:xdmType": "string", "meta:xdmField": "xdm:postOfficeBox" }, "postalCode": { "title": "Postal code", "type": "string", "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.", "meta:xdmType": "string", "meta:xdmField": "xdm:postalCode" }, "primary": { "title": "Primary", "type": "boolean", "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.", "meta:xdmType": "boolean", "meta:xdmField": "xdm:primary" }, "region": { "title": "Region", "type": "string", "description": "The region, county, or district portion of the address.", "meta:xdmType": "string", "meta:xdmField": "xdm:region" }, "repositoryCreatedBy": { "title": "Created by user identifier", "type": "string", "description": "User ID of who created the record.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryCreatedBy" }, "repositoryLastModifiedBy": { "title": "Modified by user identifier", "type": "string", "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.", "meta:xdmType": "string", "meta:xdmField": "xdm:repositoryLastModifiedBy" }, "state": { "title": "State", "type": "string", "description": "The name of the State. This is a free-form field.", "meta:xdmType": "string", "meta:xdmField": "xdm:state" }, "stateProvince": { "title": "State or province", "type": "string", "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.", "examples": [ "US-CA", "DE-BB", "JP-13" ], "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}\|)", "meta:xdmType": "string", "meta:xdmField": "xdm:stateProvince" }, "status": { "title": "Status", "type": "string", "description": "An indication as to the ability to use the address.", "default": "active", "meta:enum": { "active": "Active", "incomplete": "Incomplete", "pending_verification": "Pending verification", "blacklisted": "Blacklisted", "blocked": "Blocked" }, "meta:xdmType": "string", "meta:xdmField": "xdm:status" }, "statusReason": { "title": "Status reason", "type": "string", "description": "A description of the current status.", "meta:xdmType": "string", "meta:xdmField": "xdm:statusReason" }, "street1": { "title": "Street 1", "type": "string", "description": "Primary street level information, apartment number, street number, and street name.", "meta:xdmType": "string", "meta:xdmField": "xdm:street1" }, "street2": { "title": "Street 2", "type": "string", "description": "Optional street information second line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street2" }, "street3": { "title": "Street 3", "type": "string", "description": "Optional street information third line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street3" }, "street4": { "title": "Street 4", "type": "string", "description": "Optional street information fourth line.", "meta:xdmType": "string", "meta:xdmField": "xdm:street4" } }, "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address", "meta:xdmField": "xdm:shippingAddress" } }, "required": [ "personalEmail" ], "imsOrg": "{ORG_ID}", "meta:extensible": false, "meta:abstract": false, "meta:extends": [ "https://ns.adobe.com/xdm/context/profile-person-details", "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details", "https://ns.adobe.com/xdm/context/profile-personal-details", "https://ns.adobe.com/xdm/common/auditable", "https://ns.adobe.com/xdm/data/record", "https://ns.adobe.com/xdm/context/profile", "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691" ], "meta:xdmType": "object", "meta:registryMetadata": { "repo:createdDate": 1673310304048, "repo:lastModifiedDate": 1673380280074, "xdm:createdClientId": "{CLIENT_ID}", "xdm:lastModifiedClientId": "{CLIENT_ID}", "xdm:createdUserId": "{USER_ID}", "xdm:lastModifiedUserId": "{USER_ID}", "eTag": "c590ccc7a293040d85c2b7d93276480ef4b4aa9a4fcd6991f50fbb47f58bced2", "meta:globalLibVersion": "1.38.2" }, "meta:class": "https://ns.adobe.com/xdm/context/profile", "meta:containerId": "tenant", "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d", "meta:sandboxType": "production", "meta:tenantNamespace": "_{TENANT_ID}", "meta:immutableTags": [ "union" ], "meta:allFieldAccess": true }

{
  "$id": "https://ns.adobe.com/{TENANT_ID}/schemas/ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:altId": "_{TENANT_ID}.schemas.ee56b80adc7e03b8214e135a28538fe83c7f85bf87f565b3",
  "meta:resourceType": "schemas",
  "version": "1.4",
  "title": "Loyalty Members",
  "type": "object",
  "description": "Information for all members of the loyalty program",
  "properties": {
    "_{TENANT_ID}": {
      "type": "object",
      "properties": {
        "loyaltyTier": {
          "title": "Loyalty Tier",
          "description": "Loyalty tier info",
          "type": "object",
          "meta:xdmType": "object",
          "properties": {
            "id": {
              "title": "Loyalty Tier Identifier",
              "type": "string",
              "description": "Loyalty Tier Identifier.",
              "meta:xdmType": "string"
            },
            "effectiveDate": {
              "title": "Effective Date",
              "type": "string",
              "format": "date-time",
              "description": "Date the member joined their current loyalty tier.",
              "meta:xdmType": "date-time"
            },
            "currentThreshold": {
              "title": "Current Point Threshold",
              "type": "integer",
              "description": "The minimum number of loyalty points the member must maintain to remain in the current tier.",
              "meta:xdmType": "int"
            },
            "nextThreshold": {
              "title": "Next Point Threshold",
              "type": "integer",
              "description": "The number of loyalty points the member must accrue to graduate to the next tier.",
              "meta:xdmType": "int"
            }
          },
          "meta:referencedFrom": "https://ns.adobe.com/{TENANT_ID}/datatypes/c069d13ebfaaa5980d988e7694d794b37b1784fe11d754cb"
        }
      },
      "meta:xdmType": "object"
    },
    "_id": {
      "title": "Identifier",
      "type": "string",
      "format": "uri-reference",
      "description": "A unique identifier for the record.",
      "meta:xdmType": "string",
      "meta:xdmField": "@id"
    },
    "_repo": {
      "properties": {
        "createDate": {
          "type": "string",
          "format": "date-time",
          "meta:immutable": true,
          "meta:usereditable": false,
          "examples": [
            "2004-10-23T12:00:00-06:00"
          ],
          "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
          "meta:xdmType": "date-time",
          "meta:xdmField": "repo:createDate"
        },
        "modifyDate": {
          "type": "string",
          "format": "date-time",
          "meta:usereditable": false,
          "examples": [
            "2004-10-23T12:00:00-06:00"
          ],
          "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
          "meta:xdmType": "date-time",
          "meta:xdmField": "repo:modifyDate"
        }
      },
      "type": "object",
      "meta:xdmType": "object",
      "meta:xedConverted": true
    },
    "billingAddress": {
      "title": "Billing Address",
      "description": "Billing postal address.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "_id": {
          "title": "Coordinates ID",
          "type": "string",
          "format": "uri-reference",
          "description": "The unique identifier of the coordinates.",
          "meta:xdmType": "string",
          "meta:xdmField": "@id"
        },
        "_repo": {
          "properties": {
            "createDate": {
              "type": "string",
              "format": "date-time",
              "meta:immutable": true,
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:createDate"
            },
            "modifyDate": {
              "type": "string",
              "format": "date-time",
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:modifyDate"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "_schema": {
          "properties": {
            "description": {
              "title": "Description",
              "type": "string",
              "description": "A description of what the coordinates identify.",
              "meta:xdmType": "string",
              "meta:xdmField": "schema:description"
            },
            "elevation": {
              "title": "Elevation",
              "type": "number",
              "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:elevation"
            },
            "latitude": {
              "title": "Latitude",
              "type": "number",
              "minimum": -90,
              "maximum": 90,
              "description": "The signed vertical coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:latitude"
            },
            "longitude": {
              "title": "Longitude",
              "type": "number",
              "minimum": -180,
              "maximum": 180,
              "description": "The signed horizontal coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:longitude"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "city": {
          "title": "City",
          "type": "string",
          "description": "The name of the city.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:city"
        },
        "country": {
          "title": "Country",
          "type": "string",
          "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:country"
        },
        "countryCode": {
          "title": "Country code",
          "type": "string",
          "pattern": "^[A-Z]{2}$",
          "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:countryCode"
        },
        "createdByBatchID": {
          "title": "Created by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The dataset files in Catalog which has been originating the creation of the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:createdByBatchID"
        },
        "dmaID": {
          "title": "Designated market area",
          "type": "integer",
          "description": "The Nielsen media research designated market area.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:dmaID"
        },
        "label": {
          "title": "Label",
          "type": "string",
          "description": "Free form name of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:label"
        },
        "lastVerifiedDate": {
          "title": "Last verified date",
          "type": "string",
          "format": "date",
          "description": "The date that the address was last verified as still associated to the person.",
          "meta:xdmType": "date",
          "meta:xdmField": "xdm:lastVerifiedDate"
        },
        "modifiedByBatchID": {
          "title": "Modified by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:modifiedByBatchID"
        },
        "msaID": {
          "title": "Metropolitan statistical area",
          "type": "integer",
          "description": "The metropolitan statistical area in the United States where the observation occurred.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:msaID"
        },
        "postOfficeBox": {
          "title": "Post office box",
          "type": "string",
          "description": "Post office box of the address.",
          "maxLength": 20,
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postOfficeBox"
        },
        "postalCode": {
          "title": "Postal code",
          "type": "string",
          "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postalCode"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "region": {
          "title": "Region",
          "type": "string",
          "description": "The region, county, or district portion of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:region"
        },
        "repositoryCreatedBy": {
          "title": "Created by user identifier",
          "type": "string",
          "description": "User ID of who created the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryCreatedBy"
        },
        "repositoryLastModifiedBy": {
          "title": "Modified by user identifier",
          "type": "string",
          "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryLastModifiedBy"
        },
        "state": {
          "title": "State",
          "type": "string",
          "description": "The name of the State. This is a free-form field.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:state"
        },
        "stateProvince": {
          "title": "State or province",
          "type": "string",
          "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.",
          "examples": [
            "US-CA",
            "DE-BB",
            "JP-13"
          ],
          "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}|)",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:stateProvince"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the address.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "pending_verification": "Pending verification",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "street1": {
          "title": "Street 1",
          "type": "string",
          "description": "Primary street level information, apartment number, street number, and street name.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street1"
        },
        "street2": {
          "title": "Street 2",
          "type": "string",
          "description": "Optional street information second line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street2"
        },
        "street3": {
          "title": "Street 3",
          "type": "string",
          "description": "Optional street information third line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street3"
        },
        "street4": {
          "title": "Street 4",
          "type": "string",
          "description": "Optional street information fourth line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street4"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address",
      "meta:xdmField": "xdm:billingAddress"
    },
    "createdByBatchID": {
      "title": "Created by batch identifier",
      "type": "string",
      "format": "uri-reference",
      "description": "The dataset files in Catalog which has been originating the creation of the record.",
      "meta:xdmType": "string",
      "meta:xdmField": "xdm:createdByBatchID"
    },
    "faxPhone": {
      "title": "Fax Phone",
      "description": "Fax phone number.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "countryCode": {
          "title": "Country Calling Code",
          "type": "string",
          "description": "Country calling code (CC) as defined by E.164.",
          "minLength": 1,
          "maxLength": 3,
          "pattern": "^[0-9]{1,3}?$",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:countryCode"
        },
        "extension": {
          "title": "Extension",
          "type": "string",
          "description": "The internal dialing number used to call from a private exchange, operator, or switchboard.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:extension"
        },
        "number": {
          "title": "Number",
          "type": "string",
          "description": "The phone number. Note the phone number is a string and may include meaningful characters such as brackets '()', hyphens '-', or characters to indicate sub-dialing identifiers like extensions 'x' for example,  1-353(0)18391111 or +613 9403600x1234.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:number"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary phone number indicator. Unlike address or email address, there can be multiple primary phone numbers; one per communication channel. The communication channel is defined by the type: `textMessaging`, `mobile`, `phone`, `home`, `work`, `unknown`, and `fax`.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the phone number.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "validity": {
          "title": "Validity",
          "type": "string",
          "description": "A level of technical correctness of the phone number.",
          "meta:enum": {
            "consistent": "Consistent",
            "inconsistent": "Inconsistent",
            "incomplete": "Incomplete",
            "successfullyUsed": "Successfully used"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:validity"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/context/phonenumber",
      "meta:xdmField": "xdm:faxPhone"
    },
    "homeAddress": {
      "title": "Home Address",
      "description": "A home postal address.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "_id": {
          "title": "Coordinates ID",
          "type": "string",
          "format": "uri-reference",
          "description": "The unique identifier of the coordinates.",
          "meta:xdmType": "string",
          "meta:xdmField": "@id"
        },
        "_repo": {
          "properties": {
            "createDate": {
              "type": "string",
              "format": "date-time",
              "meta:immutable": true,
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:createDate"
            },
            "modifyDate": {
              "type": "string",
              "format": "date-time",
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:modifyDate"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "_schema": {
          "properties": {
            "description": {
              "title": "Description",
              "type": "string",
              "description": "A description of what the coordinates identify.",
              "meta:xdmType": "string",
              "meta:xdmField": "schema:description"
            },
            "elevation": {
              "title": "Elevation",
              "type": "number",
              "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:elevation"
            },
            "latitude": {
              "title": "Latitude",
              "type": "number",
              "minimum": -90,
              "maximum": 90,
              "description": "The signed vertical coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:latitude"
            },
            "longitude": {
              "title": "Longitude",
              "type": "number",
              "minimum": -180,
              "maximum": 180,
              "description": "The signed horizontal coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:longitude"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "city": {
          "title": "City",
          "type": "string",
          "description": "The name of the city.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:city"
        },
        "country": {
          "title": "Country",
          "type": "string",
          "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:country"
        },
        "countryCode": {
          "title": "Country code",
          "type": "string",
          "pattern": "^[A-Z]{2}$",
          "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:countryCode"
        },
        "createdByBatchID": {
          "title": "Created by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The dataset files in Catalog which has been originating the creation of the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:createdByBatchID"
        },
        "dmaID": {
          "title": "Designated market area",
          "type": "integer",
          "description": "The Nielsen media research designated market area.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:dmaID"
        },
        "label": {
          "title": "Label",
          "type": "string",
          "description": "Free form name of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:label"
        },
        "lastVerifiedDate": {
          "title": "Last verified date",
          "type": "string",
          "format": "date",
          "description": "The date that the address was last verified as still associated to the person.",
          "meta:xdmType": "date",
          "meta:xdmField": "xdm:lastVerifiedDate"
        },
        "modifiedByBatchID": {
          "title": "Modified by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:modifiedByBatchID"
        },
        "msaID": {
          "title": "Metropolitan statistical area",
          "type": "integer",
          "description": "The metropolitan statistical area in the United States where the observation occurred.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:msaID"
        },
        "postOfficeBox": {
          "title": "Post office box",
          "type": "string",
          "description": "Post office box of the address.",
          "maxLength": 20,
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postOfficeBox"
        },
        "postalCode": {
          "title": "Postal code",
          "type": "string",
          "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postalCode"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "region": {
          "title": "Region",
          "type": "string",
          "description": "The region, county, or district portion of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:region"
        },
        "repositoryCreatedBy": {
          "title": "Created by user identifier",
          "type": "string",
          "description": "User ID of who created the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryCreatedBy"
        },
        "repositoryLastModifiedBy": {
          "title": "Modified by user identifier",
          "type": "string",
          "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryLastModifiedBy"
        },
        "state": {
          "title": "State",
          "type": "string",
          "description": "The name of the State. This is a free-form field.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:state"
        },
        "stateProvince": {
          "title": "State or province",
          "type": "string",
          "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.",
          "examples": [
            "US-CA",
            "DE-BB",
            "JP-13"
          ],
          "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}|)",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:stateProvince"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the address.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "pending_verification": "Pending verification",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "street1": {
          "title": "Street 1",
          "type": "string",
          "description": "Primary street level information, apartment number, street number, and street name.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street1"
        },
        "street2": {
          "title": "Street 2",
          "type": "string",
          "description": "Optional street information second line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street2"
        },
        "street3": {
          "title": "Street 3",
          "type": "string",
          "description": "Optional street information third line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street3"
        },
        "street4": {
          "title": "Street 4",
          "type": "string",
          "description": "Optional street information fourth line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street4"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address",
      "meta:xdmField": "xdm:homeAddress"
    },
    "homePhone": {
      "title": "Home Phone",
      "description": "Home phone number.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "countryCode": {
          "title": "Country Calling Code",
          "type": "string",
          "description": "Country calling code (CC) as defined by E.164.",
          "minLength": 1,
          "maxLength": 3,
          "pattern": "^[0-9]{1,3}?$",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:countryCode"
        },
        "extension": {
          "title": "Extension",
          "type": "string",
          "description": "The internal dialing number used to call from a private exchange, operator, or switchboard.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:extension"
        },
        "number": {
          "title": "Number",
          "type": "string",
          "description": "The phone number. Note the phone number is a string and may include meaningful characters such as brackets '()', hyphens '-', or characters to indicate sub-dialing identifiers like extensions 'x' for example,  1-353(0)18391111 or +613 9403600x1234.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:number"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary phone number indicator. Unlike address or email address, there can be multiple primary phone numbers; one per communication channel. The communication channel is defined by the type: `textMessaging`, `mobile`, `phone`, `home`, `work`, `unknown`, and `fax`.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the phone number.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "validity": {
          "title": "Validity",
          "type": "string",
          "description": "A level of technical correctness of the phone number.",
          "meta:enum": {
            "consistent": "Consistent",
            "inconsistent": "Inconsistent",
            "incomplete": "Incomplete",
            "successfullyUsed": "Successfully used"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:validity"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/context/phonenumber",
      "meta:xdmField": "xdm:homePhone"
    },
    "loyalty": {
      "type": "object",
      "description": "Captures details related to the customer's loyalty rewards.",
      "properties": {
        "joinDate": {
          "title": "Program Join Date",
          "type": "string",
          "format": "date-time",
          "description": "Date which the visitor registered for the loyalty program.",
          "meta:xdmType": "date-time",
          "meta:xdmField": "xdm:joinDate"
        },
        "loyaltyID": {
          "title": "Program ID",
          "type": "array",
          "items": {
            "type": "string",
            "meta:xdmType": "string"
          },
          "description": "The loyalty program ID(s) associated with a specific user, if they are enrolled in the client's loyalty program.",
          "meta:xdmType": "array",
          "meta:xdmField": "xdm:loyaltyID"
        },
        "points": {
          "title": "Program Points Balance",
          "type": "number",
          "description": "Current balance of the loyalty points/awards in a visitor's loyalty account.",
          "meta:xdmType": "number",
          "meta:xdmField": "xdm:points"
        },
        "pointsExpiration": {
          "title": "Points Expiration",
          "type": "array",
          "items": {
            "type": "object",
            "properties": {
              "pointsExpirationDate": {
                "type": "string",
                "format": "date-time",
                "description": "Date on which the given portion of the loyalty points expire.",
                "meta:xdmType": "date-time",
                "meta:xdmField": "xdm:pointsExpirationDate"
              },
              "pointsExpiring": {
                "title": "Points Expiring",
                "type": "number",
                "description": "Point balance expiring as of the associated expiration date.",
                "meta:xdmType": "number",
                "meta:xdmField": "xdm:pointsExpiring"
              }
            },
            "meta:xdmType": "object"
          },
          "meta:xdmType": "array",
          "meta:xdmField": "xdm:pointsExpiration"
        },
        "pointsRedeemed": {
          "title": "Points Redeemed",
          "type": "number",
          "description": "Amount of points applied toward a purchase or otherwise redeemed.",
          "meta:xdmType": "number",
          "meta:xdmField": "xdm:pointsRedeemed"
        },
        "program": {
          "title": "Program Name",
          "type": "string",
          "description": "This should define the loyalty progam in which a visitor is enrolled.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:program"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "Captures the visitor's loyalty progam status, such as active, disabled, or suspended.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "tier": {
          "title": "Tier",
          "type": "string",
          "description": "Captures the loyalty progam tier in which a visitor is enrolled.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:tier"
        },
        "upgradeDate": {
          "title": "Program Name",
          "type": "string",
          "description": "Date which the customer was upgraded to the next tier level.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:upgradeDate"
        }
      },
      "meta:xdmType": "object",
      "meta:xdmField": "xdm:loyalty"
    },
    "mailingAddress": {
      "title": "Mailing Address",
      "description": "Mailing postal address.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "_id": {
          "title": "Coordinates ID",
          "type": "string",
          "format": "uri-reference",
          "description": "The unique identifier of the coordinates.",
          "meta:xdmType": "string",
          "meta:xdmField": "@id"
        },
        "_repo": {
          "properties": {
            "createDate": {
              "type": "string",
              "format": "date-time",
              "meta:immutable": true,
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:createDate"
            },
            "modifyDate": {
              "type": "string",
              "format": "date-time",
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:modifyDate"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "_schema": {
          "properties": {
            "description": {
              "title": "Description",
              "type": "string",
              "description": "A description of what the coordinates identify.",
              "meta:xdmType": "string",
              "meta:xdmField": "schema:description"
            },
            "elevation": {
              "title": "Elevation",
              "type": "number",
              "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:elevation"
            },
            "latitude": {
              "title": "Latitude",
              "type": "number",
              "minimum": -90,
              "maximum": 90,
              "description": "The signed vertical coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:latitude"
            },
            "longitude": {
              "title": "Longitude",
              "type": "number",
              "minimum": -180,
              "maximum": 180,
              "description": "The signed horizontal coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:longitude"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "city": {
          "title": "City",
          "type": "string",
          "description": "The name of the city.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:city"
        },
        "country": {
          "title": "Country",
          "type": "string",
          "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:country"
        },
        "countryCode": {
          "title": "Country code",
          "type": "string",
          "pattern": "^[A-Z]{2}$",
          "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:countryCode"
        },
        "createdByBatchID": {
          "title": "Created by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The dataset files in Catalog which has been originating the creation of the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:createdByBatchID"
        },
        "dmaID": {
          "title": "Designated market area",
          "type": "integer",
          "description": "The Nielsen media research designated market area.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:dmaID"
        },
        "label": {
          "title": "Label",
          "type": "string",
          "description": "Free form name of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:label"
        },
        "lastVerifiedDate": {
          "title": "Last verified date",
          "type": "string",
          "format": "date",
          "description": "The date that the address was last verified as still associated to the person.",
          "meta:xdmType": "date",
          "meta:xdmField": "xdm:lastVerifiedDate"
        },
        "modifiedByBatchID": {
          "title": "Modified by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:modifiedByBatchID"
        },
        "msaID": {
          "title": "Metropolitan statistical area",
          "type": "integer",
          "description": "The metropolitan statistical area in the United States where the observation occurred.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:msaID"
        },
        "postOfficeBox": {
          "title": "Post office box",
          "type": "string",
          "description": "Post office box of the address.",
          "maxLength": 20,
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postOfficeBox"
        },
        "postalCode": {
          "title": "Postal code",
          "type": "string",
          "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postalCode"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "region": {
          "title": "Region",
          "type": "string",
          "description": "The region, county, or district portion of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:region"
        },
        "repositoryCreatedBy": {
          "title": "Created by user identifier",
          "type": "string",
          "description": "User ID of who created the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryCreatedBy"
        },
        "repositoryLastModifiedBy": {
          "title": "Modified by user identifier",
          "type": "string",
          "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryLastModifiedBy"
        },
        "state": {
          "title": "State",
          "type": "string",
          "description": "The name of the State. This is a free-form field.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:state"
        },
        "stateProvince": {
          "title": "State or province",
          "type": "string",
          "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.",
          "examples": [
            "US-CA",
            "DE-BB",
            "JP-13"
          ],
          "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}|)",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:stateProvince"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the address.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "pending_verification": "Pending verification",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "street1": {
          "title": "Street 1",
          "type": "string",
          "description": "Primary street level information, apartment number, street number, and street name.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street1"
        },
        "street2": {
          "title": "Street 2",
          "type": "string",
          "description": "Optional street information second line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street2"
        },
        "street3": {
          "title": "Street 3",
          "type": "string",
          "description": "Optional street information third line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street3"
        },
        "street4": {
          "title": "Street 4",
          "type": "string",
          "description": "Optional street information fourth line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street4"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address",
      "meta:xdmField": "xdm:mailingAddress"
    },
    "mobilePhone": {
      "title": "Mobile Phone",
      "description": "Mobile phone number.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "countryCode": {
          "title": "Country Calling Code",
          "type": "string",
          "description": "Country calling code (CC) as defined by E.164.",
          "minLength": 1,
          "maxLength": 3,
          "pattern": "^[0-9]{1,3}?$",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:countryCode"
        },
        "extension": {
          "title": "Extension",
          "type": "string",
          "description": "The internal dialing number used to call from a private exchange, operator, or switchboard.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:extension"
        },
        "number": {
          "title": "Number",
          "type": "string",
          "description": "The phone number. Note the phone number is a string and may include meaningful characters such as brackets '()', hyphens '-', or characters to indicate sub-dialing identifiers like extensions 'x' for example,  1-353(0)18391111 or +613 9403600x1234.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:number"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary phone number indicator. Unlike address or email address, there can be multiple primary phone numbers; one per communication channel. The communication channel is defined by the type: `textMessaging`, `mobile`, `phone`, `home`, `work`, `unknown`, and `fax`.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the phone number.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "validity": {
          "title": "Validity",
          "type": "string",
          "description": "A level of technical correctness of the phone number.",
          "meta:enum": {
            "consistent": "Consistent",
            "inconsistent": "Inconsistent",
            "incomplete": "Incomplete",
            "successfullyUsed": "Successfully used"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:validity"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/context/phonenumber",
      "meta:xdmField": "xdm:mobilePhone"
    },
    "modifiedByBatchID": {
      "title": "Modified by batch identifier",
      "type": "string",
      "format": "uri-reference",
      "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.",
      "meta:xdmType": "string",
      "meta:xdmField": "xdm:modifiedByBatchID"
    },
    "person": {
      "title": "Person",
      "description": "An individual actor, contact, or owner.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "birthDate": {
          "title": "Birth date(YYYY-MM-DD)",
          "type": "string",
          "format": "date",
          "description": "The full date a person was born.",
          "meta:xdmType": "date",
          "meta:xdmField": "xdm:birthDate"
        },
        "birthDayAndMonth": {
          "title": "Birth date (MM-DD)",
          "type": "string",
          "pattern": "[0-1][0-9]-[0-9][0-9]",
          "description": "The day and month a person was born, in the format MM-DD. This field should be used when the day and month of a person's birth is known, but not the year.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:birthDayAndMonth"
        },
        "birthYear": {
          "title": "Birth year",
          "type": "integer",
          "description": "The year a person was born including the century, for example, 1983.  This field should be used when only the person's age is known, not the full birth date.",
          "minimum": 1,
          "maximum": 32767,
          "meta:xdmType": "short",
          "meta:xdmField": "xdm:birthYear"
        },
        "gender": {
          "title": "Gender",
          "type": "string",
          "enum": [
            "male",
            "female",
            "not_specified",
            "non_specific"
          ],
          "meta:enum": {
            "male": "Male",
            "female": "Female",
            "not_specified": "Not Specified",
            "non_specific": "Non-specific"
          },
          "description": "Gender identity of the person.\n",
          "default": "not_specified",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:gender"
        },
        "maritalStatus": {
          "title": "Marital Status",
          "type": "string",
          "enum": [
            "married",
            "single",
            "divorced",
            "widowed",
            "not_specified"
          ],
          "meta:enum": {
            "married": "Married",
            "single": "Single",
            "divorced": "Divorced",
            "widowed": "Widowed",
            "not_specified": "Not Specified"
          },
          "description": "Describes a person's relationship with a significant other.",
          "default": "not_specified",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:maritalStatus"
        },
        "name": {
          "title": "Full name",
          "description": "The person's full name.",
          "type": "object",
          "meta:xdmType": "object",
          "properties": {
            "courtesyTitle": {
              "title": "Courtesy title",
              "type": "string",
              "description": "Normally an abbreviation of a persons title, honorific, or salutation. The `courtesyTitle` is used in front of full or last name in opening texts. For example, Mr. Miss. or Dr.",
              "meta:xdmType": "string",
              "meta:xdmField": "xdm:courtesyTitle"
            },
            "firstName": {
              "title": "First name",
              "type": "string",
              "description": "The first segment of the name in the writing order most commonly accepted in the language of the name. In many cultures this is the preferred personal or given name. The `firstName` and `lastName` properties have been introduced to maintain compatibility with existing systems that model names in a simplified, non-semantic, and non-internationalizable way. Using `xdm:fullName` is always preferable.",
              "meta:xdmType": "string",
              "meta:xdmField": "xdm:firstName"
            },
            "fullName": {
              "title": "Full name",
              "type": "string",
              "description": "The full name of the person, in writing order most commonly accepted in the language of the name.",
              "meta:xdmType": "string",
              "meta:xdmField": "xdm:fullName"
            },
            "lastName": {
              "title": "Last name",
              "type": "string",
              "description": "The last segment of the name in the writing order most commonly accepted in the language of the name. In many cultures this is the inherited family name, surname, patronymic, or matronymic name. The `firstName` and `lastName` properties have been introduced to maintain compatibility with existing systems that model names in a simplified, non-semantic, and non-internationalizable way. Using `xdm:fullName` is always preferable.",
              "meta:xdmType": "string",
              "meta:xdmField": "xdm:lastName"
            },
            "middleName": {
              "title": "Middle name",
              "type": "string",
              "description": "Middle, alternative, or additional names supplied between the first name and last name.",
              "meta:xdmType": "string",
              "meta:xdmField": "xdm:middleName"
            },
            "suffix": {
              "title": "Suffix",
              "type": "string",
              "description": "A group of letters provided after a person's name to provide additional information. The `suffix` is used at the end of someones name. For example Jr., Sr., M.D., PhD, I, II, III, etc.",
              "meta:xdmType": "string",
              "meta:xdmField": "xdm:suffix"
            }
          },
          "meta:referencedFrom": "https://ns.adobe.com/xdm/context/person-name",
          "meta:xdmField": "xdm:name"
        },
        "nationality": {
          "title": "Nationality",
          "type": "string",
          "pattern": "^[A-Z]{2}$",
          "description": "The legal relationship between a person and their state represented using the ISO 3166-1 Alpha-2 code.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:nationality"
        },
        "taxId": {
          "title": "Tax ID",
          "type": "string",
          "description": "The Tax / Fiscal ID of the person, e.g. the TIN in the US or the CIF/NIF in Spain.",
          "meta:status": "deprecated",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:taxId"
        },
        "type": {
          "title": "Type",
          "type": "string",
          "description": "The type of individual in different business contexts like B2C.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:type"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/context/person",
      "meta:xdmField": "xdm:person"
    },
    "personID": {
      "title": "Person ID",
      "description": "Unique identifier of Person/Profile fragment.",
      "type": "string",
      "meta:xdmType": "string",
      "meta:xdmField": "xdm:personID"
    },
    "personalEmail": {
      "title": "Personal Email",
      "description": "A personal email address.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "address": {
          "title": "Address",
          "type": "string",
          "format": "email",
          "description": "The technical address, for example, 'name@domain.com' as commonly defined in RFC2822 and subsequent standards.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:address",
          "minLength": 1
        },
        "label": {
          "title": "Label",
          "type": "string",
          "description": "Additional display information that maybe available, for example, Microsoft Outlook rich address controls display 'John Smith smithjr@company.uk', 'John Smith' part is data that would be placed in the label.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:label"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary email indicator. A profile can have only one `primary` email address at a given point of time.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the email address.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "pending_verification": "Pending verification",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "type": {
          "title": "Type",
          "type": "string",
          "description": "The way the account relates to the person for example 'work' or 'personal'.",
          "meta:enum": {
            "unknown": "Unknown",
            "personal": "Personal",
            "work": "Work",
            "education": "Education"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:type"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/context/emailaddress",
      "meta:xdmField": "xdm:personalEmail",
      "required": [
        "address"
      ]
    },
    "repositoryCreatedBy": {
      "title": "Created by user identifier",
      "type": "string",
      "description": "User ID of who created the record.",
      "meta:xdmType": "string",
      "meta:xdmField": "xdm:repositoryCreatedBy"
    },
    "repositoryLastModifiedBy": {
      "title": "Modified by user identifier",
      "type": "string",
      "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.",
      "meta:xdmType": "string",
      "meta:xdmField": "xdm:repositoryLastModifiedBy"
    },
    "shippingAddress": {
      "title": "Shipping Address",
      "description": "Shipping postal address.",
      "type": "object",
      "meta:xdmType": "object",
      "properties": {
        "_id": {
          "title": "Coordinates ID",
          "type": "string",
          "format": "uri-reference",
          "description": "The unique identifier of the coordinates.",
          "meta:xdmType": "string",
          "meta:xdmField": "@id"
        },
        "_repo": {
          "properties": {
            "createDate": {
              "type": "string",
              "format": "date-time",
              "meta:immutable": true,
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was created in the repository, such as when an asset file is first uploaded or a directory is created by the server as the parent of a new asset. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:createDate"
            },
            "modifyDate": {
              "type": "string",
              "format": "date-time",
              "meta:usereditable": false,
              "examples": [
                "2004-10-23T12:00:00-06:00"
              ],
              "description": "The server date and time when the resource was last modified in the repository, such as when a new version of an asset is uploaded or a directory's child resource is added or removed. The date time property should conform to ISO 8601 standard. An example form is \"2004-10-23T12:00:00-06:00\".",
              "meta:xdmType": "date-time",
              "meta:xdmField": "repo:modifyDate"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "_schema": {
          "properties": {
            "description": {
              "title": "Description",
              "type": "string",
              "description": "A description of what the coordinates identify.",
              "meta:xdmType": "string",
              "meta:xdmField": "schema:description"
            },
            "elevation": {
              "title": "Elevation",
              "type": "number",
              "description": "The specific elevation of the defined coordinate. The value conforms to the [WGS84](http://gisgeography.com/wgs84-world-geodetic-system/) datum and is measured in meters.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:elevation"
            },
            "latitude": {
              "title": "Latitude",
              "type": "number",
              "minimum": -90,
              "maximum": 90,
              "description": "The signed vertical coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:latitude"
            },
            "longitude": {
              "title": "Longitude",
              "type": "number",
              "minimum": -180,
              "maximum": 180,
              "description": "The signed horizontal coordinate of a geographic point.",
              "meta:xdmType": "number",
              "meta:xdmField": "schema:longitude"
            }
          },
          "type": "object",
          "meta:xdmType": "object",
          "meta:xedConverted": true
        },
        "city": {
          "title": "City",
          "type": "string",
          "description": "The name of the city.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:city"
        },
        "country": {
          "title": "Country",
          "type": "string",
          "description": "The name of the government-administered territory. Other than `xdm:countryCode`, this is a free-form field that can have the country name in any language.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:country"
        },
        "countryCode": {
          "title": "Country code",
          "type": "string",
          "pattern": "^[A-Z]{2}$",
          "description": "The two-character [ISO 3166-1 alpha-2](https://datahub.io/core/country-list) code for the country.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:countryCode"
        },
        "createdByBatchID": {
          "title": "Created by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The dataset files in Catalog which has been originating the creation of the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:createdByBatchID"
        },
        "dmaID": {
          "title": "Designated market area",
          "type": "integer",
          "description": "The Nielsen media research designated market area.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:dmaID"
        },
        "label": {
          "title": "Label",
          "type": "string",
          "description": "Free form name of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:label"
        },
        "lastVerifiedDate": {
          "title": "Last verified date",
          "type": "string",
          "format": "date",
          "description": "The date that the address was last verified as still associated to the person.",
          "meta:xdmType": "date",
          "meta:xdmField": "xdm:lastVerifiedDate"
        },
        "modifiedByBatchID": {
          "title": "Modified by batch identifier",
          "type": "string",
          "format": "uri-reference",
          "description": "The last dataset files in Catalog which has modified the record. At creation time, `modifiedByBatchID` is set as `createdByBatchID`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:modifiedByBatchID"
        },
        "msaID": {
          "title": "Metropolitan statistical area",
          "type": "integer",
          "description": "The metropolitan statistical area in the United States where the observation occurred.",
          "meta:xdmType": "int",
          "meta:xdmField": "xdm:msaID"
        },
        "postOfficeBox": {
          "title": "Post office box",
          "type": "string",
          "description": "Post office box of the address.",
          "maxLength": 20,
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postOfficeBox"
        },
        "postalCode": {
          "title": "Postal code",
          "type": "string",
          "description": "The postal code of the location. Postal codes are not available for all countries. In some countries, this will only contain part of the postal code.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:postalCode"
        },
        "primary": {
          "title": "Primary",
          "type": "boolean",
          "description": "Primary address indicator. A profile can have only one `primary` address at a given point of time.",
          "meta:xdmType": "boolean",
          "meta:xdmField": "xdm:primary"
        },
        "region": {
          "title": "Region",
          "type": "string",
          "description": "The region, county, or district portion of the address.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:region"
        },
        "repositoryCreatedBy": {
          "title": "Created by user identifier",
          "type": "string",
          "description": "User ID of who created the record.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryCreatedBy"
        },
        "repositoryLastModifiedBy": {
          "title": "Modified by user identifier",
          "type": "string",
          "description": "User ID of who last modified the record. At creation time, `modifiedByUser` is set as `createdByUser`.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:repositoryLastModifiedBy"
        },
        "state": {
          "title": "State",
          "type": "string",
          "description": "The name of the State. This is a free-form field.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:state"
        },
        "stateProvince": {
          "title": "State or province",
          "type": "string",
          "description": "The state, or province portion of the observation. The format follows the [ISO 3166-2 (country and subdivision)][http://www.unece.org/cefact/locode/subdivisions.html] standard.",
          "examples": [
            "US-CA",
            "DE-BB",
            "JP-13"
          ],
          "pattern": "([A-Z]{2}-[A-Z0-9]{1,3}|)",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:stateProvince"
        },
        "status": {
          "title": "Status",
          "type": "string",
          "description": "An indication as to the ability to use the address.",
          "default": "active",
          "meta:enum": {
            "active": "Active",
            "incomplete": "Incomplete",
            "pending_verification": "Pending verification",
            "blacklisted": "Blacklisted",
            "blocked": "Blocked"
          },
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:status"
        },
        "statusReason": {
          "title": "Status reason",
          "type": "string",
          "description": "A description of the current status.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:statusReason"
        },
        "street1": {
          "title": "Street 1",
          "type": "string",
          "description": "Primary street level information, apartment number, street number, and street name.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street1"
        },
        "street2": {
          "title": "Street 2",
          "type": "string",
          "description": "Optional street information second line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street2"
        },
        "street3": {
          "title": "Street 3",
          "type": "string",
          "description": "Optional street information third line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street3"
        },
        "street4": {
          "title": "Street 4",
          "type": "string",
          "description": "Optional street information fourth line.",
          "meta:xdmType": "string",
          "meta:xdmField": "xdm:street4"
        }
      },
      "meta:referencedFrom": "https://ns.adobe.com/xdm/common/address",
      "meta:xdmField": "xdm:shippingAddress"
    }
  },
  "required": [
    "personalEmail"
  ],
  "imsOrg": "{ORG_ID}",
  "meta:extensible": false,
  "meta:abstract": false,
  "meta:extends": [
    "https://ns.adobe.com/xdm/context/profile-person-details",
    "https://ns.adobe.com/xdm/mixins/profile/profile-loyalty-details",
    "https://ns.adobe.com/xdm/context/profile-personal-details",
    "https://ns.adobe.com/xdm/common/auditable",
    "https://ns.adobe.com/xdm/data/record",
    "https://ns.adobe.com/xdm/context/profile",
    "https://ns.adobe.com/{TENANT_ID}/mixins/9068fd4ea2abf813f4fd2fc9c8b413ae453ff0efc7636691"
  ],
  "meta:xdmType": "object",
  "meta:registryMetadata": {
    "repo:createdDate": 1673310304048,
    "repo:lastModifiedDate": 1673380280074,
    "xdm:createdClientId": "{CLIENT_ID}",
    "xdm:lastModifiedClientId": "{CLIENT_ID}",
    "xdm:createdUserId": "{USER_ID}",
    "xdm:lastModifiedUserId": "{USER_ID}",
    "eTag": "c590ccc7a293040d85c2b7d93276480ef4b4aa9a4fcd6991f50fbb47f58bced2",
    "meta:globalLibVersion": "1.38.2"
  },
  "meta:class": "https://ns.adobe.com/xdm/context/profile",
  "meta:containerId": "tenant",
  "meta:sandboxId": "28e74200-e3de-11e9-8f5d-7f27416c5f0d",
  "meta:sandboxType": "production",
  "meta:tenantNamespace": "_{TENANT_ID}",
  "meta:immutableTags": [
    "union"
  ],
  "meta:allFieldAccess": true
}

recommendation-more-help

62e9ffd9-1c74-4cef-8f47-0d00af32fc07

Criar um esquema usando a API Schema Registry

Introdução

Compor um esquema com uma classe padrão

Atribuir uma classe

Pesquisar um esquema

Adicionar um grupo de campos add-a-field-group

Adicionar mais grupos de campos

Definir um novo grupo de campos

Adicionar o grupo de campos personalizados ao esquema

Visualizar o esquema atual

Criar um tipo de dados

Usar tipo de dados no esquema

Definir um descritor de identidade

Habilitar esquema para uso em Real-Time Customer Profile profile

Adicionar uma tag union

Listar esquemas em uma união

Próximas etapas

Apêndice appendix

Concluir esquema de Membros de Fidelidade complete-schema

Adicionar uma tag `union`
