Parquet
In: Generators
Description
Convert your material into a parquet floor.
A wood material converted into a parquet pattern with the Parquet filter.
| table 0-row-2 0-border-0 1-border-0 2-border-0 html-authored no-header | |
|---|---|
|
|
Parameters
Presets
Use presets to quickly change parameters to see different styles of parquet floor.
Basic parameters
- Random Seed:
The random seed determines the random values of other parameters that use randomness in this filter. - Pattern Type:
Select the parquet pattern - X Amount: 1-30
Change the number of planks on the X axis - Y Amount: 1-30
Change the number of planks on the Y axis - Seam Distance: 0-1
Modify the distance of the bevel around the seams of planks - Planks Variation: 0-1
Automatically vary color and roughness of each plank
Advanced
- English Pattern Offset: 0-1 (This parameter is only available if Basic parameters > Pattern Type is set to English)
Change the offset of each row of planks from the previous row - Seam Intensity: 0-1
Adjust the normals of the seams between planks to make them more or less noticeable - Seam Bevel Curve: 0-1
Modify the width of the bevel between planks - Seam Height Range: 0-1
Adjust the height of the seams - Planks Normal Rotation Variation: 0-1
Vary the angle of each plank by a random amount - Planks Roughness Variation: 0-1
Randomly vary the roughness of each plank.
