Adobe Scene7 is a hosted solution for managing, enhancing, publishing, and delivering rich media assets to Web, mobile, email, and Internet-connected displays and print.
You can view Experience Manager assets published in Scene7 in various viewers:
You can publish digital assets directly from Experience Manager to Scene7 and you can publish digital assets from Scene7 to Experience Manager.
This document describes how to publish digital assets from Experience Manager to Scene7 and vice versa. Viewers are also described in detail. For information on configuring Experience Manager for Scene7, see Integrating Scene7 with Experience Manager.
See also Adding Image Maps.
For more information on using video components with Experience Manager, see the following:
If Scene7 assets do not display properly, please make sure that Dynamic media is disabled and then refresh the page.
You can publish digital assets to Scene7 either from the Assets console in the classic UI or directly from the asset.
Experience Manager publishes to Scene7 asynchronously. After you click Publish, it may take several seconds for your asset to publish to Scene7.
To publish to Scene7 from the Assets console if the assets are in a Scene7 target folder:
In the Experience Manager classic UI, click Digital Assets to access the digital asset manager.
Select the asset (or assets) or folder from within the target folder you want to publish to Scene7 and right-click and select Publish to Scene7. Alternatively, you can select Publish to Scene7 from the Tools menu.
Go to Scene7 and confirm that the assets are available.
If the assets are not in a Scene7 synchronized folder, Publish to Scene7 in both menus is visible but disabled.
You can manually publish an asset as long as that asset is located inside the synchronized Scene7 folder.
If the asset is not located in the Scene7 synchronized folder, the link to Publish to Scene7 will not appear.
To publish to Scene7 directly from a digital asset:
In Experience Manager, click Digital Assets to access the digital asset manager.
Double-click to open an asset.
In the asset details pane, select Publish to Scene7.
The link changes to Publishing … and then Published. Go to Scene7 and confirm that the asset is available.
If the asset does not publish properly to Scene7, the link changes to Publishing Failed. If the asset has already been published to Scene7, the link reads Re-Publish to Scene7. Republishing allows you to make changes to an asset in Experience Manager and re-publish them.
Adobe recommends that you publish assets to Scene7 only from assets within the Scene7 target folder. However, if you need to upload assets from a folder outside of the target folder, you can still do that by uploading them to an ad-hoc folder on Scene7.
You do this by first configuring the Cloud configuration for the page where the asset will appear. You then add a Scene7 component to the page and drag and drop an asset on the component. After the page properties are set for that page, a Publish to Scene7 link appears that when selected triggers uploading to Scene7.
Assets that are in the ad-hoc folder do not appear in the Scene7 Content Browser.
To publish assets that reside outside the CQ target folder:
In Experience Manager in the classic UI, click Websites and navigate to the web page that you want to add a digital asset to that is not yet published to Scene7. (Normal page inheritance rules apply.)
In the sidekick, click the Page icon and click Page Properties.
Click Cloud Services and click Add services and select Scene7.
In the Adobe Scene7 drop-down list, select the desired configuration and click OK.
On the web page, add a Scene7 component to the desired location on the page.
From the content finder, drag a digital asset to the component. You see a link to Check Scene7 Publication Status.
If the digital asset is in the CQ target folder, then no link to Check Scene7 Publication Status appears. The assets is simply placed in the component.
Click Check Scene7 Publication Status. If the assets is not published, Experience Manager publishes the asset to Scene7. After it is uploaded, the asset is located in the ad-hoc folder. By default, the ad-hoc folder is located in the name_of_the_company/CQ5_adhoc. You can configure this, if needed.
If the asset is not in a Scene7 synchronized folder and there is no Scene7 cloud configuration associated to the current page, the upload will fail.
The following Scene7 components are available in Experience Manager:
These components are not available by default and need to be selected in Design mode before using.
After they are made available in Design mode, you can add the components to your page like any other Experience Manager component. Assets that have not yet been published to Scene7 are published to Scene7 if in a synchronized folder or on a page or with a Scene7 cloud configuration.
If you are creating and developing custom S7 viewers and using the Content Finder, you need to explicity add the allowfullscreen parameter.
Effective January 31, 2017, Adobe Scene7 will officially end-of-life support for the Flash viewer platform.
For more information about this important change, see Flash Viewer End-of-Life FAQs.
Adding a Scene7 component to a page is the same as adding a component to any page. Scene7 components are described in detail in the following sections.
To add a Scene7 component/viewer to a page in the classic UI:
In Experience Manager, open the page where you want to add the Scene7 component.
If no Scene7 components are available, click the ruler in the sidekick to enter Design mode, click Edit parsys, and select all the Scene7 components to make them available.
Return to Edit mode by clicking the pencil in the sidekick.
Drag a component from the Scene7 group in the sidekick onto the page in the desired location.
Click Edit to open the component.
Edit the component as necessary and click OK to save changes.
Responsive design for your assets means that your assets adapts depending on where it is displayed. With responsive design, the same assets can be effectively displayed on multiple devices.
To add an interactive viewing experience to a responsive site in the classic UI:
Log in to Experience Manager, and ensure that you have configured Adobe Scene7 Cloud Services and that Scene7 components are available.
If Scene7 WCM components are not available, be sure to enable them via Design mode.
In a website with the Scene7 components enabled, drag an Image viewer to the page.
Edit the component and adjust the breakpoints in the Scene7 Settings tab.
Confirm that the viewers are responsively resizing and that all interactions are optimized for desktop, tablet, and mobile.
Although configuration options vary, the following are common to all Scene7 components:
You set these configuration options by opening (double-clicking) a Scene7 component, for example, when you open a Zoom component:
The HTML5 Zoom component displays a larger image when you press the + button.
The asset has zoom tools at the bottom. Click + to enlarge. Click - to reduce. Clicking the x or the reset zoom arrow brings the image back to the original size it was imported as. Click the diagonal arrows to make it full screen. Click Edit to configure the component. With this component, you can configure settings common to all Scene7 components.
In the HTML5 Flyout component, the asset is shown as split screen; left the asset in the specified size; right the zoom portion is displayed. Click Edit to configure the component. With this component, you can configure settings common to all Scene7 components.
If your Flyout component uses a custom size, then that custom size is used and responsive setup of the component is disabled.
If your Flyout component uses the default size, as set in the Design view, then the default size is used and the component stretches to accomodate the page layout size with responsive setup of the component enabled. Be aware, however, that there is a limitation on responsive setup of the component. When the you use the Flyout component with responsive setup, you should not use it with full page stretch. Otherwise, the Flyout may extend beyond the page’s right border.
The Scene7 Image component lets you add Scene7 functionality to your images, such as Scene7 modifiers, image or viewer presets, and sharpening. The Scene7 image component is similar to other image components in Experience Manager with special Scene7 functionality. In this example, the image has the Scene7 URL modifier, &op_invert=1 applied.
Title, Alt Text In the Advanced tab, add a title to the image and alt text for those users who have graphics turned off.
URL, Open in You can set an asset from to open a link. Set the URL and in Open in indicate whether you want it to open in the same window or a new window.
Viewer preset Select an existing viewer preset from the drop-down menu. If the viewer preset you are looking for is not visible, you may need to make it visible. See Managing Viewer Presets. You cannot select a viewer preset if you are using an image preset and vice versa.
Scene7 Configuration Select the Scene7 configuration you want to use to fetch active image presets from the SPS.
Image preset Select an existing image preset from the drop-down menu. If the image preset you are looking for is not visible, you may need to make it visible. See Managing Image Presets. You cannot select a viewer preset if you are using an image preset and vice versa.
Output Format Select the output format of the image, for example jpeg. Depending on the output format you select, you may have additional configuration options. See Image Preset best practices.
Sharpening Select how you want to sharpen the image. Sharpening is explained in detail in Image Preset best practices and Sharpening best practices.
URL Modifiers You can change image effects by supplying additional S7 image commands. These are described in Image Presets and the Command reference.
Breakpoints If your website is responsive, you want to adjust the breakpoints. Breakpoints must be separated by commas (,).
Scene7 Image Templates are layered Photoshop content that was imported to Scene7, where content and properties were parameterized for variability. The Image template component lets you import images and change the text dynamically in Experience Manager. In addition, you can configure the Image template component to use values from client context, so that each user experiences the image in a personalized way.
Click Edit to configure the component. You can configure settings common to all Scene7 components as well as other settings described in this section.
File Reference, Width, Height See settings common to all Scene7 components.
Scene7 URL commands and parameters cannot be added to the File Reference URL directly. They can only be defined in the component UI in the Parameter panel.
Title, Alt Text In the Scene7 Image Template tab, add a title to the image and alt text for those users who have graphics turned off.
URL, Open in You can set an asset from to open a link. Set the URL and in Open in indicate whether you want it to open in the same window or a new window.
Parameter Panel When importing an image, the parameters are pre-populated with information from the image. If there is no content that can be dynamically changed, this window is empty.
To change the text dynamically, enter new text in the fields and click OK. In this example, the Price is now $50 and shipping is 99 cents.
The text in the image changes. You can reset the text back to the original value by clicking Reset next to the field.
To link a field to a client context value, click Select to open the client-context menu, select the client context, and click OK. In this example, the name changes based on linking the Name with the formatted name in the profile.
The text reflects the name of the currently logged in user. You can reset the text back to the original value by clicking Reset next to the field.
To make the Scene7 image template component a clickable link:
On the page with the Scene7 image template component, click Edit.
In the URL field, enter the URL that users go to when the image is clicked. In the Open in field, select whether you want the target to open (a new window or same window).
The Scene7 Video component (available from the Scene7 section of the sidekick) uses device and bandwidth detection to serve the right video to each screen. This component is an HTML5 video player; it is a single viewer that can be used cross channel.
It can be used for adaptive video sets, a single MP4 video, or a single F4V video.
See Video for more information on how videos work with Scene7 integration. In addition, see how the Scene7 video component compares to the foundation video component.
Adobe DAM and WCM shows if a primary source video is uploaded. They do not show these proxy assets:
When using an adaptive video set with the Scene7 video component, the component will need to resized to fit he dimensions of the video.
The Scene7 content browser lets you view content from Scene7 directly in Experience Manager. To access the content browser, in the Content Finder, select Scene7 in the touch-optimized user interface or the S7 icon in the classic user interface. Functionality is identical between both user interfaces.
If you have multiple configurations, Experience Manager by default displays the default configuration. You can select different configurations directly in the Scene7 content browser in the drop-down menu.
Browse content in Scene7 by clicking the S7 tab.
You can change the configuration you are accessing by selecting the configuration.The folders change depending on which configuration you select.
As with the content finder for Assets, you can search for assets and filter results. However, unlike the Assets finder, when entering a keyword in the S7 tab, the file name starts with the string that you entered, rather than containing the keyword in the file name.
By default, assets are displayed by file name. You can also filter results by asset type.
For video, the Scene7 content browser of WCM supports:
Searching for Scene7 assets is similar to searching Experience Manager assets except that when you search you are actually seeing a remote view of the assets in the Scene7 system, rather than importing them directly into Experience Manager.
You can use either the classic UI or the touch-optimized UI to both view and search for assets. Depending on the interface, how you search is slightly different.
When searching in either UI, you can filter by the following criteria (shown here in the touch-optimized UI):
Enter keywords You can search assets by name. When searching the keywords you enter is what the file name starts with. For example, typing the word “swimming” would look for any asset file names that start with those letters in that order. Be sure to click enter after you type the term to find the asset.
Folder/path The name of the folder that appears is based on the configuration you have selected. You can drill down to lower levels by clicking the folder icon and selecting a sub-folder, then clicking the checkmark to select it.
If you enter a keyword and select a folder, Experience Manager searches that folder and any sub-folders. However, if you do not enter any keywords when searching, selecting the folder will only show the assets in that folder and will not include any subfolders.
By default, Experience Manager searches the folder selected and all sub-folders.
Type of Asset Select Scene7 to browse Scene7 content. This option is only available if Scene7 has been configured.
Configuration If you have more than one Scene7 configuration defined in Cloud Services, you can select it here. As a result the folder will change based on the configuration you have chosen.
Asset type Within the Scene7 browser, you can filter results to include any of the following: images, templates, videos, and adaptive video sets. If you do not select any asset type, Experience Manager by default searches all asset types.
In the classic UI, you can also search for Flash and FXG. Filtering for these in the touch-optimized UI is currently not supported.
When searching video, you are searching a single rendition. Results return the original rendition (only *.mp4) and the encoded rendition.
When searching an adaptive video set, you are searching the folder and all sub-folders but only if you have added a keyword to the search. If you have not added a keyword, Experience Manager does not search the sub-folders.
Publish Status You can filter for assets based on publication status: Unpublished or Published. If you do not select any Publish Status, Experience Manager by default searches all publish statuses.
