透過範例了解通用編輯器可以在屬性面板中編輯的欄位和元件類型。了解如何藉由建立模型定義並連結至元件來檢測自己的應用程式。

概觀 overview

調整自己的應用程式以便與通用編輯器搭配使用時，必須檢測元件並在編輯器的屬性面板中定義其可操作的欄位和元件類型。透過建立模型並從元件連結至該模型，便可以達成上述目標。

本文件提供模型定義以及您可使用的欄位和元件類型的概觀，並附上範例設定。

TIP

若您不熟悉如何針對通用編輯器檢測自己的應用程式，請參閱 AEM 開發人員通用編輯器概觀文件。

模型定義結構 model-structure

為透過通用編輯器中的屬性面板設定元件，必須具備模型定義並將其連結至該元件。

模型定義是 JSON 結構，以模型陣列開頭。

[
  {
    "id": "model-id",        // must be unique
    "fields": []             // array of fields which shall be rendered in the properties panel
  }
]

參閱本文件的「欄位」區段，了解關於定義 fields 陣列的更多資訊。

您可以透過兩種方式將模型連結至元件：使用元件定義或透過檢測。

使用元件定義進行連結 component-definition

這是將模型連結至元件的首選方法。這樣做可以讓您在元件定義中集中維護連結，並能夠在各個容器之間拖曳元件。

只需在 component-definition.json 檔案之 components 陣列的元件物件中包含 model 屬性即可。

如需詳細資訊，請參閱元件定義文件。

使用檢測進行連結 instrumentation

若要將模型定義與元件搭配使用，可以使用 data-aue-model 屬性。

<div data-aue-resource="urn:datasource:/content/path" data-aue-type="component"  data-aue-model="model-id">Click me</div>

NOTE

通用編輯器首先會檢查模型是否透過檢測進行連結，並在檢查元件定義之前使用該模型。這表示：

已經透過檢測實施模型連結的專案會繼續依照原樣運作，不需要進行任何變更。
如果您在元件定義以及檢測中定義模型，則會一直使用檢測。

載入模型定義 loading-model

模型建立後，即可將其視為外部檔案進行參照。

<script type="application/vnd.adobe.aue.model+json" src="<url-of-model-definition>"></script>

或者您也可以內聯定義模型。

<script type="application/vnd.adobe.aue.model+json">
  { ... model definition ... }
</script>

欄位 fields

欄位物件具有以下類型定義。

設定

值類型

說明

必要

component

ComponentType

元件的轉譯工具

是

name

string

應保留資料的屬性或路徑

是

label

FieldLabel

欄位的標籤

是

description

FieldDescription

欄位的說明

否

value

FieldValue

這是預設值，可作為預留位置。此值不會驅動任何內容更新。它只是UI中的一種表示法。

否

valueType

ValueType

標準驗證，可以是 string、string[]、number、date、boolean

否

required

boolean

欄位是否為必填

否

readOnly

boolean

欄位是否為唯讀

否

hidden

boolean

欄位是否預設隱藏

否

condition

RulesLogic

根據條件顯示或隱藏欄位的規則

否

multi

boolean

欄位是否為多欄位
請注意，屬性面板中的多欄位不允許容器巢狀

否

validation

ValidationType

驗證規則或欄位的規則

否

raw

unknown

元件可以使用的原始資料

否

名稱欄位和巢狀 nesting

name 欄位可以直接指向目前資源的屬性，或者若是在 cq:Pages 的元件，也可以使用巢狀屬性的路徑。例如：

"name": "teaser/image/fileReference"

元件類型 component-types

以下是可用於轉譯欄位的元件類型。

說明

元件類型

aem-tag

aem-content

boolean

checkbox-group

container

aem-content-fragment

日期時間

date-time

體驗片段

aem-experience-fragment

multiselect

number

radio-group

reference

richtext

select

tab

text

AEM 標記 aem-tag

AEM 標記元件類型會啟用 AEM 標記選取器，可用於將標記附加至元件。

範例

code language-json
`{ "id": "aem-tag-picker", "fields": [ { "component": "aem-tag", "label": "AEM Tag Picker", "name": "cq:tags", "valueType": "string" } ] }`

螢幕擷圖

TIP

請參閱管理分類資料文件，了解如何使用試算表管理 Edge Delivery Services 專案分類資料的更多資訊。

AEM 內容 aem-content

AEM 內容元件類型會啟用 AEM 內容選取器，可用於選取任何 AEM 資源。與只能選取資產的參照元件不同，AEM 內容元件可以參照任何 AEM 內容。其提供額外的驗證類型。

驗證類型

值類型

說明

必要

rootPath

string

內容選取器將開啟供使用者選取 AEM 內容的路徑，將選取範圍限制為該目錄和子目錄

否

範例

code language-json

code language-json
`{ "id": "aem-content-picker", "fields": [ { "component": "aem-content", "name": "reference", "value": "", "label": "AEM Content Picker", "valueType": "string", "validation": { "rootPath": "/content/refresh" } } ] }`

{
  "id": "aem-content-picker",
  "fields": [
    {
      "component": "aem-content",
      "name": "reference",
      "value": "",
      "label": "AEM Content Picker",
      "valueType": "string",
      "validation": {
            "rootPath": "/content/refresh"
        }
    }
  ]
}

螢幕擷圖

布林值 boolean

布林元件類型會儲存簡單真/假值並轉譯為切換功能。其提供額外的驗證類型。

驗證類型

值類型

說明

必要

customErrorMsg

string

如果輸入的值不是布林值時會顯示的訊息

否

範例 1

code language-json
`{ "id": "boolean", "fields": [ { "component": "boolean", "label": "Boolean", "name": "boolean", "valueType": "boolean" } ] }`

範例 2

code language-json
`{ "id": "another-boolean", "fields": [ { "component": "boolean", "label": "Boolean", "name": "boolean", "valueType": "boolean", "validation": { "customErrorMsg": "Think, McFly. Think!" } } ] }`

螢幕擷圖

核取方塊群組 checkbox-group

與布林值類似，核取方塊群組元件類型允許選取多個真/假項目，轉譯為多個核取方塊。

範例

code language-json

code language-json
`{ "id": "checkbox-group", "fields": [ { "component": "checkbox-group", "label": "Checkbox Group", "name": "checkbox", "valueType": "string[]", "options": [ { "name": "Option 1", "value": "option1" }, { "name": "Option 2", "value": "option2" } ] } ] }`

{
  "id": "checkbox-group",
  "fields": [
    {
      "component": "checkbox-group",
      "label": "Checkbox Group",
      "name": "checkbox",
      "valueType": "string[]",
      "options": [
        { "name": "Option 1", "value": "option1" },
        { "name": "Option 2", "value": "option2" }
      ]
    }
  ]
}

螢幕擷圖

容器 container

容器元件類型能夠對元件進行分組，包括多欄位支援。其提供一項額外的設定。請注意，屬性面板中的多重欄位不允許容器巢狀

設定

值類型

說明

必要

collapsible

boolean

容器是否可摺疊

否

範例

code language-json

code language-json
`{ "id": "container", "fields": [ { "component": "container", "label": "Container", "name": "container", "valueType": "string", "collapsible": true, "fields": [ { "component": "text-input", "label": "Simple Text 1", "name": "text", "valueType": "string" }, { "component": "text-input", "label": "Simple Text 2", "name": "text2", "valueType": "string" } ] } ] }`

 {
  "id": "container",
  "fields": [
    {
      "component": "container",
      "label": "Container",
      "name": "container",
      "valueType": "string",
      "collapsible": true,
      "fields": [
        {
          "component": "text-input",
          "label": "Simple Text 1",
          "name": "text",
          "valueType": "string"
        },
        {
          "component": "text-input",
          "label": "Simple Text 2",
          "name": "text2",
          "valueType": "string"
        }
      ]
    }
  ]
}

螢幕擷圖

多欄位支援

code language-json

code language-json
`{ "component": "container", "name": "test", "label": "Multi Text", "multi": true, "fields": [ { "component": "reference", "name": "image", "value": "", "label": "Sample Image", "valueType": "string" }, { "component": "text", "name": "alt", "value": "", "label": "Alt Text", "valueType": "string" } ] }`

{
  "component": "container",
  "name": "test",
  "label": "Multi Text",
  "multi": true,
  "fields": [
    {
      "component": "reference",
      "name": "image",
      "value": "",
      "label": "Sample Image",
      "valueType": "string"
    },
    {
      "component": "text",
      "name": "alt",
      "value": "",
      "label": "Alt Text",
      "valueType": "string"
    }
  ]
}

內容片段 content-fragment

內容片段選取器可用於選取內容片段及其變化版本 (如需要)。其提供一項額外的設定。

設定

值類型

說明

必要

variationName

string

用於儲存所選變化版本的變數名稱。若未定義，則不顯示變化版本選取器

否

其亦提供額外的驗證類型。

驗證類型

值類型

說明

必要

rootPath

string

內容選取器將開啟供使用者選取內容片段的路徑，將選取範圍限制為該目錄和子目錄

否

NOTE

通用編輯器根據其模型驗證內容片段欄位，讓您能夠強制執行資料完整性規則，例如規則運算式模式和唯一條件限制。

這可在發佈之前確保您的內容符合特定業務需求。

範例 1

code language-json

code language-json
`[ { "id": "aem-content-fragment", "fields": [ { "component": "aem-content-fragment", "name": "picker", "label": "Content Fragment Picker", "valueType": "string", "variationName": "contentFragmentVariation", "validation": { "rootPath": "/content/refresh" } } ] } ]`

[
  {
    "id": "aem-content-fragment",
    "fields": [
      {
        "component": "aem-content-fragment",
        "name": "picker",
        "label": "Content Fragment Picker",
        "valueType": "string",
        "variationName": "contentFragmentVariation",
        "validation": {
            "rootPath": "/content/refresh"
        }
      }
    ]
  }
]

螢幕擷圖

日期時間 date-time

日期時間元件類型允許指定日期、時間或其組合。其提供另外的設定。

設定

值類型

說明

必要

displayFormat

string

顯示日期字串的格式

是

valueFormat

string

儲存日期字串的格式

是

其亦提供額外的驗證類型。

驗證類型

值類型

說明

必要

customErrorMsg

string

若 valueFormat 未符合，則會顯示此訊息

否

範例 1

code language-json
`{ "id": "date-time", "fields": [ { "component": "date-time", "label": "Date & Time", "name": "date", "valueType": "date" } ] }`

範例 2

code language-json

code language-json
{ "id": "another-date-time", "fields": [ { "component": "date-time", "valueType": "date-time", "name": "field1", "label": "Date Time", "description": "This is a date time field that stores both date and time.", "required": true, "placeholder": "YYYY-MM-DD HH:mm:ss", "displayFormat": null, "valueFormat": null, "validation": { "customErrorMsg": "Marty! You have to come back with me!" } }, { "component": "date-time", "valueType": "date", "name": "field2", "label": "Another Date Time", "description": "This is another date time field that only stores the date.", "required": true, "placeholder": "YYYY-MM-DD", "displayFormat": null, "valueFormat": null, "validation": { "customErrorMsg": "Back to the future!" } }, { "component": "date-time", "valueType": "time", "name": "field3", "label": "Yet Another Date Time", "description": "This is another date time field that only stores the time.", "required": true, "placeholder": "HH:mm:ss", "displayFormat": null, "valueFormat": null, "validation": { "customErrorMsg": "Great Scott!" } } ] }

{
  "id": "another-date-time",
  "fields": [
    {
      "component": "date-time",
       "valueType": "date-time",
      "name": "field1",
      "label": "Date Time",
      "description": "This is a date time field that stores both date and time.",
      "required": true,
      "placeholder": "YYYY-MM-DD HH:mm:ss",
      "displayFormat": null,
      "valueFormat": null,
      "validation": {
        "customErrorMsg": "Marty! You have to come back with me!"
      }
    },
    {
      "component": "date-time",
      "valueType": "date",
      "name": "field2",
      "label": "Another Date Time",
      "description": "This is another date time field that only stores the date.",
      "required": true,
      "placeholder": "YYYY-MM-DD",
      "displayFormat": null,
      "valueFormat": null,
      "validation": {
        "customErrorMsg": "Back to the future!"
      }
    },
    {
      "component": "date-time",
      "valueType": "time",
      "name": "field3",
      "label": "Yet Another Date Time",
      "description": "This is another date time field that only stores the time.",
      "required": true,
      "placeholder": "HH:mm:ss",
      "displayFormat": null,
      "valueFormat": null,
      "validation": {
        "customErrorMsg": "Great Scott!"
      }
    }
  ]
}

螢幕擷圖

體驗片段 experience-fragment

體驗片段選取器可用於選取體驗片段及其變化版本 (如需要)。其提供一項額外的設定。

設定

值類型

說明

必要

variationName

string

用於儲存所選變化版本的變數名稱。若未定義，則不顯示變化版本選取器

否

其亦提供額外的驗證類型。

驗證類型

值類型

說明

必要

rootPath

string

內容選取器將開啟供使用者選取體驗片段的路徑，將選取範圍限制為該目錄和子目錄

否

範例 1

code language-json

code language-json
`[ { "id": "experience-fragment", "fields": [ { "component": "aem-experience-fragment", "valueType": "string", "name": "experience-fragment", "label": "experience-fragment", "variationName": "experienceFragmentVariation", "validation": { "rootPath": "/content/refresh" } } ] } ]`

[
  {
    "id": "experience-fragment",
    "fields": [
      {
        "component": "aem-experience-fragment",
        "valueType": "string",
        "name": "experience-fragment",
        "label": "experience-fragment",
        "variationName": "experienceFragmentVariation",
        "validation": {
            "rootPath": "/content/refresh"
        }
      }
    ]
  }
]

螢幕擷圖

多重選取 multiselect

多重選取元件類型在下拉式選單中顯示多個可供選取的項目，也能夠將可選元素分組。

範例 1

code language-json

code language-json
`{ "id": "multiselect", "fields": [ { "component": "multiselect", "name": "multiselect", "label": "Multi Select", "valueType": "string", "options": [ { "name": "Option 1", "value": "option1" }, { "name": "Option 2", "value": "option2" } ] } ] }`

{
  "id": "multiselect",
  "fields": [
    {
      "component": "multiselect",
      "name": "multiselect",
      "label": "Multi Select",
      "valueType": "string",
      "options": [
        { "name": "Option 1", "value": "option1" },
        { "name": "Option 2", "value": "option2" }
      ]
    }
  ]
}

範例 2

code language-json

code language-json
`{ "id": "multiselect-grouped", "fields": [ { "component": "multiselect", "name": "property", "label": "Multiselect field", "valueType": "string", "required": true, "maxSize": 2, "options": [ { "name": "Theme", "children": [ { "name": "Light", "value": "light" }, { "name": "Dark", "value": "dark" } ] }, { "name": "Type", "children": [ { "name": "Alpha", "value": "alpha" }, { "name": "Beta", "value": "beta" }, { "name": "Gamma", "value": "gamma" } ] } ] } ] }`

{
  "id": "multiselect-grouped",
  "fields": [
    {
      "component": "multiselect",
      "name": "property",
      "label": "Multiselect field",
      "valueType": "string",
      "required": true,
      "maxSize": 2,
      "options": [
        {
          "name": "Theme",
          "children": [
            { "name": "Light", "value": "light" },
            { "name": "Dark",  "value": "dark" }
          ]
        },
        {
          "name": "Type",
          "children": [
            { "name": "Alpha", "value": "alpha" },
            { "name": "Beta", "value": "beta" },
            { "name": "Gamma", "value": "gamma" }
          ]
        }
      ]
    }
  ]
}

螢幕擷圖

數字 number

數字元件類型允許輸入數字。其提供額外的驗證類型。

驗證類型

值類型

說明

必要

numberMin

number

允許的最小數字

否

numberMax

number

允許的最大數字

否

customErrorMsg

string

若未到達 numberMin 或 numberMax，則會顯示的訊息

否

範例 1

code language-json
`{ "id": "number", "fields": [ { "component": "number", "name": "number", "label": "Number", "valueType": "number", "value": 0 } ] }`

範例 2

code language-json

code language-json
`{ "id": "another-number", "fields": [ { "component": "number", "valueType": "number", "name": "field1", "label": "Number Field", "description": "This is a number field.", "required": true, "placeholder": null, "validation": { "numberMin": 0, "numberMax": 88, "customErrorMsg": "You also need 1.21 gigawatts." } } ] }`

{
  "id": "another-number",
  "fields": [
   {
      "component": "number",
      "valueType": "number",
      "name": "field1",
      "label": "Number Field",
      "description": "This is a number field.",
      "required": true,
      "placeholder": null,
      "validation": {
        "numberMin": 0,
        "numberMax": 88,
        "customErrorMsg": "You also need 1.21 gigawatts."
      }
    }
  ]
}

螢幕擷圖

單選按鈕群組 radio-group

單選按鈕群組元件類型允許從多個選項中進行互斥選取，並轉譯為類似核取方塊群組的群組。

範例

code language-json

code language-json
`{ "id": "radio-group", "fields": [ { "component": "radio-group", "label": "Radio Group", "name": "radio", "valueType": "string", "options": [ { "name": "Option 1", "value": "option1" }, { "name": "Option 2", "value": "option2" } ] } ] }`

{
  "id": "radio-group",
  "fields": [
    {
      "component": "radio-group",
      "label": "Radio Group",
      "name": "radio",
      "valueType": "string",
      "options": [
        { "name": "Option 1", "value": "option1" },
        { "name": "Option 2", "value": "option2" }
      ]
    }
  ]
}

螢幕擷圖

參照 reference

參照元件類型會啟用 AEM 資產選取器，可用於選取要參照的任何 AEM 資產。與可以選取任何 AEM 資源的 AEM 內容元件不同，參照元件僅能參照資產。其提供額外的驗證類型。

參照元件類型允許從目前的物件參照另一個資料物件。

範例

code language-json
`{ "id": "reference", "fields": [ { "component": "reference", "label": "Reference", "name": "reference", "valueType": "string" } ] }`

螢幕擷圖

RTF 文字 rich-text

RTF 文字允許多行、RTF 文字的輸入內容。

範例 1

code language-json
`{ "id": "richtext", "fields": [ { "component": "richtext", "name": "rte", "label": "Rich Text", "valueType": "string" } ] }`

螢幕擷圖

選取 select

選取元件類型允許從下拉式選單的預定義選項清單中選取單一選項。

範例

code language-json

code language-json
`{ "id": "select", "fields": [ { "component": "select", "label": "Select", "name": "select", "valueType": "string", "options": [ { "name": "Option 1", "value": "option1" }, { "name": "Option 2", "value": "option2" } ] } ] }`

{
  "id": "select",
  "fields": [
    {
      "component": "select",
      "label": "Select",
      "name": "select",
      "valueType": "string",
      "options": [
        { "name": "Option 1", "value": "option1" },
        { "name": "Option 2", "value": "option2" }
      ]
    }
  ]
}

螢幕擷圖

標籤 tab

標籤元件類型可讓您在多個標籤上將其他輸入欄位組合在一起，改善作者的版面編排。

tab 定義可以視為是 fields 陣列中的分隔符號。tab 之後的所有內容都會被放置在該標籤上，直到出現新的 tab，其後的項目便會放置在新標籤上。

若您希望有項目出現在所有標籤之上，則必須在任何標籤之前定義這些項目。

範例

code language-json

code language-json
`{ "id": "tab", "fields": [ { "component": "tab", "label": "Tab 1", "name": "tab1" }, { "component": "text-input", "label": "Text 1", "name": "text1", "valueType": "string" }, { "component": "tab", "label": "Tab 2", "name": "tab2" }, { "component": "text-input", "label": "Text 2", "name": "text2", "valueType": "string" } ] }`

{
  "id": "tab",
  "fields": [
    {
      "component": "tab",
      "label": "Tab 1",
      "name": "tab1"
    },
    {
      "component": "text-input",
      "label": "Text 1",
      "name": "text1",
      "valueType": "string"
    },
    {
      "component": "tab",
      "label": "Tab 2",
      "name": "tab2"
    },
    {
      "component": "text-input",
      "label": "Text 2",
      "name": "text2",
      "valueType": "string"
    }
  ]
}

螢幕擷圖

文字 text

文字允許輸入單行文字。其包括額外的驗證類型。

驗證類型

值類型

說明

必要

minLength

number

允許的最小字元數

否

maxLength

number

允許的最大字元數

否

regExp

string

輸入文字必須符合的規則運算式

否

customErrorMsg

string

若違反 minLength、maxLength 和/或 regExp 則會顯示的訊息

否

範例 1

code language-json
`{ "id": "simpletext", "fields": [ { "component": "text", "name": "text", "label": "Simple Text", "valueType": "string" } ] }`

範例 2

code language-json

code language-json
`{ "id": "another simpletext", "fields": [ { "component": "text", "name": "text", "label": "Simple Text", "valueType": "string", "valueFormat": "regexp", "description": "This is a text input with validation.", "required": true, "validation": { "minLength": 1955, "maxLength": 1985, "regExp": "^foo:.*", "customErrorMsg": "Why don't you make like a tree and get outta here?" } } ] }`

{
  "id": "another simpletext",
  "fields": [
    {
      "component": "text",
      "name": "text",
      "label": "Simple Text",
      "valueType": "string",
      "valueFormat": "regexp",
      "description": "This is a text input with validation.",
      "required": true,
      "validation": {
        "minLength": 1955,
        "maxLength": 1985,
        "regExp": "^foo:.*",
        "customErrorMsg": "Why don't you make like a tree and get outta here?"
      }
    }
  ]
}

螢幕擷圖

recommendation-more-help

fbcff2a9-b6fe-4574-b04a-21e75df764ab
