了解使用AEM Dynamic Media进行颜色管理 understanding-color-management-with-aem-dynamic-media

在本视频中,我们将介绍Dynamic Media色彩管理,以及如何使用它在for AEM Assets中提供色彩校正预览功能。

NOTE
在AEM中启用Dynamic Media以使用此功能。

此功能作为Feature Pack在AEM 6.1和6.2版本中提供。

颜色管理配置节点的XML模板 xml-template-for-the-color-management-configuration-node

下面是“颜色管理”配置节点的XML模板。 可以将此XML模板复制到AEM开发项目中,并使用与项目相应的配置对其进行配置。

<?xml version="1.0" encoding="UTF-8"?>

<!--
    XML Node definition for: /etc/dam/imageserver/configuration/jcr:content/settings

 Adobe Docs

 * Image Server Configuration: https://docs.adobe.com/docs/en/aem/6-2/administer/content/dynamic-media/config-dynamic.html#Configuring%20Dynamic%20Media%20Image%20Settings

* Default Color Profile Configuration: https://docs.adobe.com/docs/en/aem/6-1/administer/content/dynamic-media/config-dynamic.html#Configuring%20the%20default%20color%20profiles

    iccprofileXXX values:
        Node name of color profile found at: /etc/dam/imageserver/profiles

    iccblackpointcompensation values:
        true | false

    iccdither values:
        true | false

    iccrenderintent values:
        0 for perceptual
        1 for relative colorimetric
        2 for saturation
        3 for absolute colorimetric

-->

<jcr:root xmlns:sling="http://sling.apache.org/jcr/sling/1.0" xmlns:cq="http://www.day.com/jcr/cq/1.0"
    xmlns:jcr="http://www.jcp.org/jcr/1.0" xmlns:nt="http://www.jcp.org/jcr/nt/1.0"
    jcr:primaryType="nt:unstructured"

        bkgcolor="FFFFFF"
        defaultpix="300,300"
        defaultthumbpix="100,100"
        expiration="{Long}36000000"
        jpegquality="80"
        maxpix="2000,2000"
        resmode="SHARP2"
        resolution="72"
        thumbnailtime="[1%,11%,21%,31%,41%,51%,61%,71%,81%,91%]"
        iccprofilergb=""
        iccprofilecmyk=""
        iccprofilegray=""
        iccprofilesrcrgb=""
        iccprofilesrccmyk=""
        iccprofilesrcgray=""
        iccblackpointcompensation="{Boolean}true"
        iccdither="{Boolean}false"
        iccrenderintent="{Long}0"
/>

默认Adobe颜色配置文件的列表如下 list-of-default-adobe-color-profiles-are-listed-below

名称
色彩空间
描述
adobergb
RGB
Adobe RGB (1998)
AppleRGB
RGB
AppleRGB
CIERGB
RGB
CIERGB
CoatedFogra27
CMYK
涂层的FOGRA27 (ISO 12647-2:2004)
CoatedFogra39
CMYK
涂层纸FOGRA39 (ISO 12647-2:2004)
CoatedGraCol
CMYK
涂层纸GRACoL 2006 (ISO 12647-2:2004)
ColorMatchRGB
RGB
ColorMatchRGB
欧洲ISOCoated
CMYK
欧洲ISO铜版FOGRA27
EuroscaleCoated
CMYK
Euroscale Coated v2
EuroscaleUncoated
CMYK
Euroscale Uncoated v2
JapanColorCoated
CMYK
Japan Color 2001涂布
JapanColorPaper
CMYK
《日本彩色2002报纸》
JapanColorUncoated
CMYK
Japan Color 2001无涂层
JapanColorWebCoated
CMYK
Japan Color 2003 Web Coated
Japanawebcoated
CMYK
日本Web Coated (Ad)
新闻纸快照2007
CMYK
美国新闻纸(SNAP 2007)
NTSC
RGB
NTSC (1953年)
PAL
RGB
PAL/SECAM
ProPhoto
RGB
ProPhotoRGB
PS4默认
CMYK
Photoshop 4默认CMYK
PS5默认
CMYK
Photoshop 5默认CMYK
SheetfedCoated
CMYK
U.S. Sheetfed Coated v2
SheetfedUncoated
CMYK
U.S. Sheetfed Uncoated v2
SMPTE
RGB
SMPTE-C
sRGB
sRGBRGB
IEC61966-2.1
UncoatedFogra29
CMYK
无涂层的FOGRA29 (ISO 12647-2:2004)
WebCoat
CMYK
U.S. Web Coated (SWOP) v2
WebCoatedFogra28
CMYK
网页涂层的FOGRA28 (ISO 12647-2:2004)
WebCoatedGrade3
CMYK
Web涂层的SWOP 2006 3级纸
WebCoatedGrade5
CMYK
Web涂层的SWOP 2006 5级纸
WebUncoated
CMYK
U.S. Web Uncoated v2
宽色域RGB
RGB
宽色域RGB
