Grunge Damas

Last update: Thu Feb 26 2026 00:00:00 GMT+0000 (Coordinated Universal Time)

{width="200px"}

In: Texture Generators*/Noises*

Simple

Description

The Grunge Damas node generates a grunge map akin to a Damascus steel pattern.

Parameters

  • Balance FloatAdjusts the balance between dark and bright values.

  • Contrast FloatAdjusts the contrast of the image.

  • Invert BooleanInverts the output of the image, using a 1-x operation.

  • Non Square Expansion BooleanEnables compensation of squash and stretch with non-square ratios.

  • Advanced

    • Distortion FloatAdjusts the amount of distortion in the pattern.
    • Divisions IntegerAdjusts the amount of divisions, or gradient repetitions, in the pattern.
    • Waves IntegerAdjusts the amount of waves in the pattern.
    • Details FloatAdjusts the intensity of the smaller distortions.
    • Rotation Random FloatAdjusts the randomness of the rotation for each wave.

Example Images

{width="256px"}
