Flip
In: SDF function > Transform
Description
Applies a mirror transform to the input SDF shape.
Essentially performs a negative scale on the selected axes.
INFO
To learn more about concepts and workflows involving SDF functions, go to the dedicated page: Working with SDF functions
Inputs
SDF Float
The input SDF shape.
Mirror axis Integer3
Use an Integer3 to set the desired mirror axis.
E.g. (1, 0, 0) will mirror the X axis.
Default: (1, 0, 0)
E.g. (1, 0, 0) will mirror the X axis.
Default: (1, 0, 0)
P Float3
The transformed world space position. Use this input to apply additional transformations using the Offset P and Rotate P nodes.
Default: The untransformed world space position.
Default: The untransformed world space position.
