Elongated cylinder
In: SDF function > Primitive
Description
An SDF function for an elongated cylinder of adjustable length, radius and rounding of edges.
The elongated cylinder is the result of bridging two cylinders.
Inputs
Inputs
Height Float
The Z-up height of both the start and end cylinders from their base.
Default: 0.5
Default: 0.5
Radius Float
The radius of both the start and end cylinders.
Default: 0.5
Default: 0.5
Rounding Float
The radius of the rounded arcs applied to the elongated cylinder’s edges.
Note: hard edges may appear where the rounding radiuses intersect.
Default: 0
Note: hard edges may appear where the rounding radiuses intersect.
Default: 0
Center position Float3
The world space position of the pivot of the elongated cylinder.
Default: (0, 0, 0)
Default: (0, 0, 0)
Elongation distance Float
The distance along which the start cylinder is elongated.
I.e. the distance between the centers of the start and end cylinders.
Default: 0.5
I.e. the distance between the centers of the start and end cylinders.
Default: 0.5
P Float3
The transformed world space position. Use this input to apply additional transformations using the Offset P and Rotate P nodes.
Default: The untransformed world space position.
Default: The untransformed world space position.
