Cube

Size Float3

The size of the cube on X, Y and Z.

Default: (1, 1, 1)

Rounding Float

The radius of the rounded arcs applied to the cube’s edges.

Note: hard edges may appear where the rounding radiuses intersect.

Default: 0

Pivot position (local) Float3

The world space position of the local pivot of the cube, where (0, 0, 0) places the pivot at the center of the cube.

Default: (0, 0, -0.5)

Center position Float3

The world space position of the pivot of the cube.

Default: (0, 0, 0)

P Float3

The transformed world space position. Use this input to apply additional transformations using the Offset P and Rotate P nodes.

Default: The untransformed world space position.
