Capped torus
In: SDF function > Primitive
Description
An SDF function for a capped torus, where the sweeping of the minor circle along a major circle can be capped at an angle.
Both circles have adjustable radiuses.
INFO
To learn more about concepts and workflows involving SDF functions, go to the dedicated page: Working with SDF functions
Inputs
Major radius Float
The radius of the major circle along which the minor circle is swept to form the surface of the torus.
Default: 0.5
Default: 0.5
Minor radius Float
The radius of the minor circle being swept along the major circle to form the surface of the torus.
Default: 0.2
Default: 0.2
Angle Float
The central angle, in turns, defining the trimming arc of the major circle along which the minor circle will not be swept.
Default: 0.75
Default: 0.75
Angle offset Float
The offset, along the major radius, of the trimming arc along which the minor circle will not be swept.
Default: 0
Default: 0
Symmetrical Boolean
Controls whether the trimming arc should be drawn in one or two directions.
Default: True
Default: True
Center position Float3
The world space position of the pivot of the capped torus.
Default: (0, 0, 0.5)
Default: (0, 0, 0.5)
P Float3
The transformed world space position. Use this input to apply additional transformations using the Offset P and Rotate P nodes.
Default: The untransformed world space position.
Default: The untransformed world space position.
