Advanced URL Configurations

Last update: April 24, 2024

Topics:
Commerce Integration Framework

CREATED FOR:

Admin
Developer

NOTE

Search Engine Optimization (SEO) has become a key concern for many marketers. As a result, SEO concerns must be addressed on many AEM Projects. See SEO and URL Management Best Practices for additional information.

AEM CIF Core Components provides advanced configurations to customize the URLs for product and category pages. Many implementations customize these URLs for search engine optimization (SEO) purposes. The following video details how to configure the UrlProvider Service and features of Sling Mapping to customize the URLs for product and category pages.

Configuration

To configure the UrlProvider service according to the SEO requirements and needs a project must provide an OSGI configuration for the “CIF URL Provider configuration”.

NOTE

Since release 2.0.0 of the AEM CIF Core Components, the URL Provider configuration only provides pre-defined url formats, instead of the free-text configureable formats known from 1.x releases. Furthermore the use of selectors to pass data in URLs has been replaced with suffixes.

Product Page URL Format

This configures the URLs of the product pages and supports the following options:

{{page}}.html/{{sku}}.html#{{variant_sku}} (default)
{{page}}.html/{{url_key}}.html#{{variant_sku}}
{{page}}.html/{{sku}}/{{url_key}}.html#{{variant_sku}}
{{page}}.html/{{url_path}}.html#{{variant_sku}}
{{page}}.html/{{sku}}/{{url_path}}.html#{{variant_sku}}

If there is the Venia Reference store:

{{page}} is replaced by /content/venia/us/en/products/product-page
{{sku}} is replaced by the product’s SKU, for example, VP09
{{url_key}} is replaced by the product’s url_key property, for example, lenora-crochet-shorts
{{url_path}} is replaced by the product’s url_path, for example, venia-bottoms/venia-pants/lenora-crochet-shorts
{{variant_sku}} is replaced by the currently selected variant, for example, VP09-KH-S

Since the url_path got deprecated, the pre-defined product URL formats use a product’s url_rewrites and pick the one with the most path segments as alternative if the url_path is not available.

With the above example data, a product variant URL formatted using the default URL format looks like /content/venia/us/en/products/product-page.html/VP09.html#VP09-KH-S.

Category Page URL Format

This configures the URLs of the category or product list pages and supports the following options:

{{page}}.html/{{url_path}}.html (default)
{{page}}.html/{{url_key}}.html

If there is the Venia Reference store:

{{page}} is replaced by /content/venia/us/en/products/category-page
{{url_key}} is replaced by the category’s url_key property
{{url_path}} is replaced by the category’s url_path

With the above example data, a category page URL formatted using the default URL format looks like /content/venia/us/en/products/category-page.html/venia-bottoms/venia-pants.html.

NOTE

The url_path is a concatenation of the url_keys of a product or category’s ancestors and the product or category’s url_key separated by / slash.

Specific Category-/Product-Pages

It is possible to create multiple category and product pages for only a specific subset of categories or products of a catalog.

The UrlProvider is pre-configured to generate deep links to such pages on author tier instances. This is useful to editors, that browse a site using Preview mode, navigate to a specific product or category page and switch back to Edit mode to edit the page.

On publish tier instances on the other hand, catalog page urls should be kept stable to not lose gains on search engine rankings for example. Because of that publish tier instances will not render deep links to specific catalog pages per default. To change this behavior, the CIF URL Provider Specific Page Strategy can be configured to always generate specific page urls.

Custom URL Formats

To provide a custom URL format that a project can implement either the ProductUrlFormat or the CategoryUrlFormat service interface and register the implementation as OSGI service. Those implementations, if available, replace the configured, pre-defined format. If there are multiple implementations registered, the one with the higher service ranking replaces the ones with the lower service ranking.

The custom URL format implementations must implement a pair of methods to build a URL from given parameters, and to parse a URL to return the same parameters respectively.

Combine with Sling Mappings

In addition to the UrlProvider, it is also possible to configure Sling Mappings to rewrite and process URLs. The AEM Archetype project also provides an example configuration to configure some Sling Mappings for port 4503 (publish) and 80 (Dispatcher).

Combine with AEM Dispatcher

URL rewrites can also be achieved by using AEM Dispatcher HTTP server with mod_rewrite module. The AEM Project Archetype provides a reference AEM Dispatcher config which already includes basic rewrite rules for the generated size.

Example

The Venia Reference store project includes sample configurations to demonstrate the usage of custom URLs for product and category pages. This allows each project to set up individual URL patterns for product and category pages according to their SEO needs. A combination of CIF UrlProvider and Sling Mappings as described above is used.

NOTE

This configuration must be adjusted with the external domain used by the project. The Sling Mappings are working based on the hostname and domain. Therefore this configuration is disabled by default and must be enabled before deployment. To do so rename the Sling Mapping hostname.adobeaemcloud.com folder in ui.content/src/main/content/jcr_root/etc/map.publish/https according to the used domain name and enable this config by adding resource.resolver.map.location="/etc/map.publish" to the JcrResourceResolver config of the project.
