SQL Data Management sql-data-management

The SQL Data Management activity lets you write your own SQL scripts to create and populate work tables.

Prerequisites prerequisites

Before configuring the activity, make sure the following prerequisites are fulfilled:

  • The activity is available for remote data sources only.
  • The Outbound schema must exist in the database and be linked to an FDA database.

Configuring the SQL Data Management activity configuring-the-sql-data-management-activity

  1. Specify the activity Label.

  2. Select the External account to use, then select the Outbound schema linked to this external account.

    note caution
    CAUTION
    The Outbound schema is fixed and cannot be edited.
  3. Add the SQL script.

    note caution
    CAUTION
    It is the SQL script writer’s responsibility to make sure that the SQL script is functional, and that its references (fields names, etc.) are in accordance with the Outbound schema.

    If you want to load an existing SQL code, select the The SQL script is contained in an entity stored in the database option. SQL scripts must be created and stored in the Administration / Configuration / SQL scripts menu.

    Otherwise, type or copy-paste your SQL script in the dedicated area.

    The activity lets you use the following variables in the script:

    • activity.tableName: SQL name of the outbound work table.

    • task.incomingTransitionByName(‘name’).tableName: SQL name of the work table carried by the incoming transition to use (the transition is identified by its name).

      note note
      NOTE
      The (‘name’) value corresponds to the Name field from the transition properties.
  4. If the SQL script already contains commands to create an outbound work table, unselect the Automatically create work table option. Otherwise, a work table is automatically created once the workflow executes.

  5. Click Ok to confirm the activity configuration.

The activity is now configured. It is ready to be executed in the workflow.

CAUTION
Once the activity executed, the outbound transition records count is indicative only. It may vary according to the level of complexity of the SQL script.
If the activity is restarted, the whole script is executed from its beginning, regardless of it execution status.

SQL script samples sql-script-samples

NOTE
The script samples in this section are meant to be executed under PostgreSQL.

Below script lets you create a work table and insert data into this same work table:

CREATE UNLOGGED TABLE <%= activity.tableName %> (
  iRecipientId INTEGER DEFAULT 0,
  sFirstName VARCHAR(100),
  sMiddleName VARCHAR(100),
  sLastName VARCHAR(100),
  sEmail VARCHAR(100)
);

INSERT INTO <%= activity.tableName %>
SELECT iRecipientId, sFirstName, sMiddleName, sLastName, sEmail
FROM nmsRecipient
GROUP BY iRecipientId, sFirstName, sMiddleName, sLastName, sEmail;

Below script lets you perform a CTAS operation (CREATE TABLE AS SELECT) and create a work table index:

CREATE TABLE <%= activity.tableName %>
AS SELECT iRecipientId, sEmail, sFirstName, sLastName, sMiddleName
FROM nmsRecipient
WHERE sEmail IS NOT NULL
GROUP BY iRecipientId, sEmail, sFirstName, sLastName, sMiddleName;

CREATE INDEX ON <%= activity.tableName %> (sEmail);

ANALYZE <%= activity.tableName %> (sEmail);

Below script lets you merge two working tables:

CREATE TABLE <%= activity.tableName %>
AS SELECT i1.sFirstName, i1.sLastName, i2.sEmail
FROM <%= task.incomingTransitionByName('input1').tableName %> i1
JOIN <%= task.incomingTransitionByName('input2').tableName %> i2 ON (i1.id = i2.id)
